Defender Digital Video Recorder Instruction Manual page 48

PLAYBACK
s f
oftWare UnCtions
The software has many functions. The drop down menus allow you to adjust the video, the file menu allows you to
open video files, and settings allows you to adjust certain settings in the software.
Play Menu
4 5
The video functions from the play menu are as follows:
1. Add Videos:
2. Remove Videos:
3. Clear All:
4. Rewind:
5. Minute Bar:
6. Open:
7. Backward Frame:
8. Play/ Pause:
9. Forward Frame:
10. Stop:
11. Fast Forward:
12. Volume Bar:
13. Capture Picture:
14. Show/ Hide File List: Displays the video files that have been added to view. Also hides the list.
6 7
Add a single video or a folder of multiple videos to the playback list.
Remove a single unwanted video clip from the playback list.
Clears all videos from the playback list.
Moves the video backwards.
Shows your progress of time through any footage being played.
Opens the last folder you accessed to add videos.
Moves the video backward a frame.
Pressing PLAY plays the footage. Once PLAY is pressed, the PAUSE l l button will appear.
Moves the video forward a frame.
Stops the footage.
Slows down video.
Allows you to adjust the volume if you have recorded footage from an audio-enabled
camera (not included).
This option takes a photo of the screen. When you select this option, a screenshot of the
current video will be saved under a computer directory. The file location will appear
beside the capture button.
8 9 10
1 2 3
11 12 13 14
48
