Defender Digital Video Recorder Instruction Manual page 82

TROUBLESHOOTING
Cannot see all/one of the
camera(s) on the monitor
I have lost video footage
The cameras are not
appearing in
sequence mode
Nothing is recording
however all the images are
appearing on the screen
The camera picture is
too dark
The night vision will not
turn on/I can't see at night
My DVR will not acquire an
IP address
The NETWORK SETTINGS
screen on the DVR has no
information
• Check if the cameras are properly connected to the back of the DVR and to a
power source.
• If using the 4 to 1 power connector, make sure it is plugged into a power
source and each of the cameras.
• Check CAMERA SETUP from the MAIN MENU to see if any of the cameras are
turned off.
• The cameras might have been tampered with. Be sure to check that all
connections are secure and properly set.
• The HDD overwrite feature is enabled. When enabled, the DVR will begin
overwriting the earliest stored footage when the HDD is full.
• Unplug the power to the cameras and/or DVR and plug it back in.
• Check if you have selected START ROTATE in the FUNCTION TOOLBAR. The
cameras will start to sequence according to the sequence dwell time.
• You must be in LIVE viewing mode.
• To stop, click STOP ROTATE in the FUNCTION TOOLBAR.
• You must initiate the recording to start by pressing the RECORD button on
the remote.
• Check under Record Setup in the main menu to make sure all the cameras are
set to ON.
• Check your record schedule to make sure the DVR is set to record that hour.
• Verify that the HDD is installed and formatted in the DEVICE menu.
• Adjust the camera's brightness settings under MAIN
MENU→CAMERA→COLOR.
• Try moving your camera to a brighter area.
• Make sure the camera is not pointing directly into a light source.
• Your camera may not be getting enough light towards it during the day.
Adjust the sunshade (top of camera) to allow more sunlight.
• Night vision turns on automatically when the sensor detects a lack of light. If
your cameras are in a space with too much light, the night vision will not
turn on.
• Check the Ethernet connections, ensure that the connection lights are lit (on
the router and the back of DVR).
• Try using a different Ethernet cable and/or a different port on your router.
• Be sure the DVR is properly connected to the router. There should be green link
indicator lights if the DVR is properly connected.
• Make sure the DVR IP Allocation is set to DHCP. This is a standard default
setting that will work in most networking situations.
• Power cycle the DVR to ensure it is properly connected and the IP Allocation is
set to DHCP.
82
