- Page 1 Mobile Video Studio MS-900 INSTRUCTION MANUAL http:// www.datavideo-tek.com...
-
Page 2: Table Of Contents
Disclaimer of Product and Services The information offered in this instruction manual is intended as a guide only. At all times, Datavideo Technologies will try to give correct, complete and suitable information. However, Datavideo Technologies cannot exclude that some information in this manual, from time to time, may not be correct or may be incomplete. -
Page 3: Warnings And Precautions
The MS-900 is heavy – approximately 70Kg. A minimum of 2 people are required to lift or move this product. The MS-900 should be always lifted and placed in an upright position; do not place or try to move the unit in any other position as damage or injury could result. There are two carry handles on either side of the product, please use these handles to safely share the weight between the people lifting the MS-900. -
Page 4: Warranty
Certain parts with limited lifetime expectancy such as LCD Panels, DVD Drives, Hard Drives are only covered for the first 10,000 hours, or 1 year (whichever comes first). Any second year warranty claims must be made to your local Datavideo office or one of its authorized Distributors before the extended warranty expires. -
Page 5: Ms-900 Packing List & Accessories
MS-900 Packing List & Accessories MS-900 case including the following factory fitted and pre-cabled items TLM-170 Monitor DN-500 Recorder ITC-100 Talk back system Control Panel (SE-900 Mixer) Base Unit (SE-900 Mixer) RP31 – Rear connection plate for Talk back system PD-1 –... -
Page 6: Introduction
Introduction The Datavideo MS-900 mobile video studio is a ready to go solution; it will save a lot of your valuable time when setting up or breaking down in the field. To get the most out of this product please read this user manual, and the other associated user manuals supplied within the Manual Binder to familiarise yourself with all the products within the MS-900. -
Page 7: Unpacking The Se-900 Control Panel Keyboard
Unpacking the SE-900 Control Panel Keyboard The SE-900 Control Panel Keyboard is held in its shipping position by a securing bolt on either side. To lower the Control Panel first remove the securing bolts as indicated below. The bolts can then be stored on each hinge bracket before lowering the Control Panel Keyboard. Setting up the TLM-170 17”... -
Page 8: Rear Connections
SDI output card also available S-video & CV composite input. Bare Bones MS-900 rear panel shown - your configuration will be different depending on your order. Front Overview Please refer to the individual instruction manual of each item for more details on actual operation. -
Page 9: Rear Overview
Each product built into the MS-900 receives DC power from the PD-1 unit on the rear of the MS-900. Please ensure the PD-1 is fed with either an AC or DC feed before attempting to switch on the MS-900. For more information on the PD-1 please refer to its manual. -
Page 10: Service And Support
It is our goal to make your products ownership a satisfying experience. Our support staff are available to assist you in setting up and operating your system. Please refer to our web site www.datavideo-tek.com for answers to common questions, support requests or contact your local office below.
