Battery Replacement
WARNING: To avoid electric shock, disconnect the test leads from any source of voltage
before removing the battery/fuse cover.
1. Disconnect the test leads from the meter.
2. Remove the rubber holster (if in place).
3. Remove the two screws securing the rear cover using a Phillips head screwdriver.
4. Lift the cover off and replace the battery observing the correct polarity.
5. Insert the new battery into the battery holder.
6. Replace the rear cover and secure with the screws.
Never dispose of used batteries or rechargeable batteries in household waste.
As consumers, users are legally required to take used batteries to appropriate
collection sites, the retail store where the batteries were purchased, or wherever
batteries are sold.
Disposal: Do not dispose of this instrument in household waste. The user is
obligated to take end‐of‐life devices to a designated collection point for the disposal
of electrical and electronic equipment.
Other Battery Safety Reminders
o Never dispose of batteries in a fire. Batteries may explode or leak.
o Never mix battery types. Always install new batteries of the same type.
Fuse Replacement
WARNING: To avoid electric shock, disconnect the test leads from any source of voltage
before removing battery/fuse cover.
1.
Disconnect the test leads from any circuit being measured.
2.
Remove the rubber holster (if in place).
3.
Remove the two screws securing the rear cover using a Phillips head screwdriver. Remove the
rear cover.
4.
Remove the old fuse by gently pulling up on it.
5.
Install the new fuse by gently pushing it into the holder.
6.
Always use a fuse of the proper size and value; 250mA/250V fast blow.
7.
Replace the rear cover and secure with the screws.
