Note: Whether your wine
cooler can reach the actual
set temperature depends on
the ambient environmental
conditions.
Allow at least 24 hours
before storing your wines
and to allow the temperature
to acclimate.
Caution: If you powered off
the unit, please wait at least
5 minutes before powering it
back on.
EdgeStar Wine Refrigerator

OPERATION

Installation Check List before Operation

1. Have all packing materials and tape been removed from the interior and
exterior of the wine refrigerator?
2. Have the installation instructions been followed, including connecting the
machine to electricity? And has proper grounding been installed for the wine
refrigerator?
3. Has the machine been leveled?
4. Is the wine refrigerator in a site where the ambient temperature is between 50º
F and 95º F all year round?
5. Is there a clearance of at least 2/5" at the rear, 1/5" at the top and 1/5" at the
sides for proper air circulation?

Using the Temperature Control Panel

Use the and buttons to adjust the temperature. The temperature
displayed can be in Fahrenheit or Celsius. This wine cooler has a
temperature range from 40°F to 54°F for the upper zone, and 54°F to
64°F for the lower zone.
This wine cooler has two displays, a Set Display that shows the set
temperature, and a Current Temperature Display that shows the current
temperature. Note: It is normal to see the set temperature and current
temperature displays being a few degrees off from each other.
Press the button on the control panel to lower the temperature by 1
degree increments for the upper zone. Once the temperature setting is
set at 40° pressing the button again will take it back to 54°
Press the button on the control panel to lower the temperature by 1
degree increments for the lower zone. Once the temperature setting is
set at 54° pressing the button again will take it back to 64°
Press the button to turn the inner light on or off.
Press and hold the power button for approximately 3 seconds to turn the
unit's power on or off. The Run Light will illuminate when the unit is
working.
The Celsius or Fahrenheit light will be lit depending on what scale
temperature is being displayed. To switch between C and F, press and
hold the and buttons at the same time for approximately 5 seconds
until the temperature scale changes.
8
