COLOR VIDEO DOOR PHONE CAV-72B
Thank you for purchasing COMMAX products.
Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
The company is not responsible for any safety accidents caused by abnormal operation of the product.
Advertisement
Table of Contents
Related Manuals for Commax CAV-72B
Summary of Contents for Commax CAV-72B
- Page 1 COLOR VIDEO DOOR PHONE CAV-72B 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133 Thank you for purchasing COMMAX products. Web site : www.commax.com Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly.
-
Page 2: Table Of Contents
Table of Contents Warnings and caution CAV-72B Part Name & Function Features and Main Functions CDT-180 Part Name & Function Package contents System Layout Wiring Diagram Installation Method Operating Description 1. Door Answering & Monitoring 2. Interphone 3. Connecting the Main Unit and the DECT Phone Menu/ Set 1. -
Page 3: Warnings And Caution
Warnings and caution Make sure to follow the instructions to prevent any danger or property losses. It indicates prohibition. It indicates prohibition of disassembly. Warning Death or serious It indicates prohibition of contact. injury is expected. It indicates dos and don’ts. It indicates that the plug should be pulled out from the socket. - Page 4 Install the product in a flat and Pull the plug if the product is If the product generates strange stable place. not used for a long time. sound, make sure to pull the Otherwise, it may not function plug immediately and contact properly. Commax service center.
-
Page 5: Cav-72B Part Name & Function
1. CAV-72B The Function and Name of Each Part function Name Details Lamp, while using DECT phone Indicate that DECT phone is under usage. Handset The phone’ s handset receiver Security/ RED lamp for security, Automatic recording lamp GREEN lamp for automatic recording set. -
Page 6: Features And Main Functions
2. Features and main Function 1. Features 7” Wide TFT-LCD ● Surface type ● Free voltage power source ● OSD (On screen Display) ● 2. Main function Door Answering & Monitoring ● Interphone call ● Image storing 128 cuts : Auto & Manual record ●... -
Page 7: Cdt-180 Part Name & Function
3. CDT-180 The Function and Name of Each Part Receiver Color LCD -Receiving incoming call -Receiving new message message Function display -Flash at new message Redial / Back / Clear Up/Down Key -Menu Up/Down Menu button Menu/ OK/ Option -Setting change Down : Left/Right Key -Cursor movement... -
Page 8: Package Contents
4. Package Contents User manual Wall Bracket Monitor & Handset Fixing Screw Fixing Screw DECT Wireless Phone (CDT-180) 1. Additional CDT-180 purchase is required 2. Contents - Battery - Adapter... -
Page 9: System Layout
5. System Layout images Mast Main Unit Connectable Products. ● Camera : Max. 4EA ① Main distributor : 1EA ② ③ Master Unit: Max. 20 EA (Can connect up to 5 units per port in the main distributor) ④ Dect Phone : Max. 4 EA Wiring ●... -
Page 10: Wiring Diagram
6. Wiring Diagram images CAUTION ● -The monitor can connect up to 5 EA per port from the main distributor. -Be careful of the polarity. -It is recommended to use UTP(CAT. 5) but it is possible to use from 26AWG to 20AWG. -Please be careful of the polarity as the shown in the picture. - Page 11 Wiring between CCTV Camera to Main Distributor ● -All ports for the camera on the main distributor are available for using the CCTV or Door Camera units. -Power source is separately required per CCTV Camera -The type of Coaxial Cable depends on the distance of installation. To.
-
Page 12: Installation Method
-Avoid installing this product where there is magnetic force, humidity, direct exposure under the sun and near heating apparatus. -The recommendable installation height for CAV-72B is 1450 ~ 1500mm. -It is better for DECT phone to be charged after finishing installation. -
Page 13: Operating Description
8. Operation Description 1) Door Answering & Monitoring When you push the CALL button on camera, you can hear the chime sound from ① the monitor and visitor’ s image will be shown on a screen * Duration of on-screen: 30 Seconds OSD : [Cam1 call] To talk to visitor, push the TALK button and then you can talk in the hands-free mode. -
Page 14: Interphone
2) Interphone This function is to call to other room unit and talk with other room unit. If you push the INTERPHONE button, each room ID will be shown in the form of [Room#] as below. [Interphone] ROOM 01 ... -
Page 15: Connecting The Main Unit And The Dect Phone
3) Connecting the Main Unit and the DECT Phone This DECT phone has various functions from a normal DECT phone. Door Call ① When you receive a call from door, pick up the DECT Phone from the adaptor and press the TALK button and you can talk, To end the talk, put down the DECT Phone to the adaptor or push the PAUSE button. -
Page 16: Room Id Setting
Use the Right(▷) button and then select a setting using the SET(Y) button and cancel ② (N) button and push the ENT button to exit the MENU. It is possible only when all magnetic switches connected to main unit are closed (holding time : 60sec) OSD : [Burglar Y or N] ※... -
Page 17: Screen Adjustment
Screen Adjustment... -
Page 18: Dect Phone Registration
5) DECT Phone Registration Before usage of any wireless phone, each phone must be registered with ① the DECT base unit. Registering a Wireless Phone Registering... Base ↲ Redia Exit Menu >> Handset Set >> Register >> Base # ID >> Enter PIN ②... -
Page 19: Rec./Image) Image Memory
10. (REC./IMAGE) Image Memory [Image memory] Review ▶ Time Set Auto Record DEL Whole Memory ▲ ▼ : Select Menu ENT : Menu Det REC/ MAGE: Turn Off 1) Playback Press the REC./IMAGE button ① Use the UP,DOWN keys to select the Review mode/option and press ENTER ②... -
Page 20: Time Set
Time set 2) Time Set 23-JUN-07 11:12:33 Press the REC./IMAGE button. ▲ ① Day Set Use the UP,DOWN keys to select the ② Complete : ENT ‘Time Set’mode and press ENTER. Use the LEFT,RIGHT keys to advance through the time setting options ③... -
Page 21: Trouble Shooting
11. Trouble shooting If you think that the product has trouble, please first check below contents before you ask a repair. Troubles Check Point Actions 1. Please connect the 1.The power supply The power supply is power supply cord code is missing or not. ●... -
Page 22: Specifications
12. Specification ITEM CAV-72B Central unit: 6 wires, MASTER : 6 wires, TEL: 2 wires Wiring number AC100-240V~, 50/60Hz Rated voltage HANDS-FREE : Voice switch method , HANDSET(Wire) *Option : DECT Talk method 7.7cm(7” )TFT-LCD Display unit Door(individual door):ring electronic chime 3 sounds...
