General Information; Model Number Description - Trane INTELLIPAK Installation Operation & Maintenance

Model Number Description

All products are identified by a multiple character model number listed on the unit nameplate. An explanation of the alphanumeric identifi-
cation code is provided below. Its use can define the unit's specific components, type of application, i.e. CV or VAV, for a particular unit.
When ordering replacement parts or requesting service, be sure to refer to the specific model number, serial number, and DL number (if
applicable) stamped on the unit nameplate.
Sample Model No.: S X H F - *20 4 0 A 1
Digit No.: 1 2 3 4 5,6,7 8 9 10 11 12 13 14 15 16 17 18 19 20 21+
Digit 1 - Unit Type
S = Self-Contained
Digit 2 - Unit Function
A = DX Cooling, No Heat
E = DX Cooling, Electric Heat
F = DX Cooling, Natural Gas Heat
L = DX Cooling, Hot Water Heat
S = DX Cooling, Steam Heat
X = DX Cooling, Extended Casings
# = DX Cooling, Propane Gas Heat
Digit 3 - Unit Airflow
H = Single-Zone
Digit 4 - Development Sequence
F = Sixth
Digits 5, 6, 7 - Nominal Capacity
*20 = 20 Tons *55 = 55 Tons
*25 = 25 Tons *60 = 60 Tons
*30 = 30 Tons *70 = 70 Tons
*40 = 40 Tons *75 = 75 Tons
*50 = 50 Tons
Digit 8 - Power Supply
4 = 460/60/3 XL
5 = 575/60/3 XL
E = 200/60/3 XL
F = 230/60/3 XL
Note: SEHF units (unit with
electric heat) utilizing 208V or
230V require dual power source.
Digit 9 - Heating Capacity
Note: When the second digit
calls for "F" (Gas Heat), the
following values apply:
Additionally, please note G and
M available ONLY on 50 Ton
models and above.
H = High Heat - 2 Stage
L = Low Heat - 2 Stage
0 = No Heat
J = Limited Modulating High Heat
G = Limited Modulating Low Heat
P = Full Modulating High Heat
M = Full Modulating Low Heat
Note: When the second digit
calls for "E" (electric heat), the
following values apply:
D = 30 KW R = 130 KW
H = 50 KW U = 150 KW
L = 70 KW V = 170 KW
N = 90 KW W = 190 KW
Q = 110 KW
Note: When the second digit calls
"L" (Hot Water) or "S" (Steam)
Heat, one of the following valve
size values must be in Digit 9:
High Heat Coil: 1 = 50", 2 = .75",
3 = 1", 4 = 1.25", 5 = 1.5", 6 = 2".
Low Heat Coil: A = .50", B = .75",
C = 1", D = 1.25", E = 1.5", F = 2".
1. Available as standard 460 volt only for 70 and 75 ton models
2. * in digit 5 indicates C or F
0 A 1 5 B 1 D
Digit 10 - Design Sequence
3 = Disconnect Redesign
Note: Sequence may be any letter
A thru Z, or any digit 1 thru 9.
Digit 11 - Exhaust Option
0 = None
1 = Barometric
2 = 100% - 1.5 HP*
3 = 100% - 3 HP*
4 = 100% - 5 HP*
5 = 100% - 7.5 HP*
6 = 100% - 10 HP*
7 = 100% - 15 HP*
8 = 100% - 20 HP*
A = 50% - 1.5 HP
B = 50% - 3 HP
C = 50% - 5 HP
D = 50% - 7.5 HP
E = 100% - 1.5 HP**
F = 100% - 3 HP**
G = 100% - 5 HP**
H = 100% - 7.5 HP**
J = 100% - 10 HP**
K = 100% - 15 HP**
L = 100% - 20 HP**
# = 50% w/ Statitrac
* w/Statitrac
** w/o Statitrac (CV only)
Digit 12 - Exhaust Fan Drive
0 = None 8 = 800 PRM
4 = 400 RPM 9 = 900 RPM
5 = 500 RPM A = 1000 RPM
6 = 600 RPM B = 1100 RPM
7 = 700 RPM
Digit 13 - Filter Type
A = Throwaway
B = Cleanable Wire Mesh
C = High-Efficiency Throwaway
D = Bag with Prefilters
E = Cartridge with Prefilters
F = No Filters (T/A Rack Only)
G = No Filters (Bag/Cart. Rack Only)
Digit 14 - Supply Fan Horsepower
1 = 3.0 HP 6 = 20.0 HP
2 = 5.0 HP 7 = 25.0 HP
3 = 7.5 HP 8 = 30.0 HP
1
4 = 10.0 HP 9 = 40.0 HP
5 = 15.0 HP
Digit 15 - Supply Fan Drive
5 = 500 RPM B = 1100 RPM
6 = 600 RPM C = 1200 RPM
7 = 700 RPM D = 1300 RPM
8 = 800 RPM E = 1400 RPM
9 = 900 RPM F = 1500 RPM
A = 1000 RPM G = 1600 RPM
Digit 16 - Fresh Air Section
A = No Fresh Air
B = 0-25% Manual
D = 0-100% Economizer
4

General Information

0 1 A,R,L,etc.
Digit 17 - System Control
1 = CV Control (Zone Control)
2 = VAV-(S/A Temp Control
without Inlet Guide Vanes)
3 = VAV-(S/A Temp Control
with Inlet Guide Vanes)
4 = Space Pressure Control with Exhaust VFD
without Bypass
5 = Space Pressure Control with Exhaust VFD
and Bypass
6 = VAV Supply Air Temperature Control
with VFD w/o Bypass
7 = VAV Supply Air Temperature Control
with VFD and Bypass
8 = Supply and Exhaust Fan with VFD
without Bypass
9 = Supply and Exhaust Fan with VFD
and Bypass
Digit 18 - Accessory Panel
0 = None
A = BAYSENS008*
B = BAYSENS010*
C = BAYSENS013*
D = BAYSENS014*
E = BAYSENS019*
F = BAYSENS020*
G = BAYSENS021*
Digit 19 - Ambient Control
0 = Standard
1 = 0 Degree Fahrenheit
Digit 20 - Agency Approval
0 = None (UL Gas Heater, see note)
1 = UL
2 = CSA
Note: Includes UL clsssified gas heating
section only when second digit of
Model No. is a "F".
Digits 21 - 38 - Miscellaneous
21 A = Unit Disconnect Switch
22 B = Hot Gas Bypass
23 C = Economizer Control w/Comparative
Enthalpy
23 Z = Economizer Control w/Reference
Enthalpy
23 W = Economizer Control w/Dry Bulb
23 O = None W/O Economizer
24 E = Low Leak Fresh Air Dampers
25 F = High Duct Temperature Thermostat
26 G = High Capacity Evaporator Coil
H = Hi Cap Evap Coil & Hi Eff Cond Coil (25,30,50 Ton only)
27 H = Copper Fins (Cond. only)
28 K = Generic B.A.S. Module
29 L = High-Efficiency Motors (Supply & Exhaust)
30 M = Remote Human Interface
31 N = Ventilation Override Module
32 R = Extended Grease Lines
33 T = Access Doors
34 V = Interprocessor Communications Bridge
35 0 = No communication module
35 Y = Trane Communication Interface Module
35 7 = LonTalk® Communication Interface Module
36 8 = Spring Isolators
37 6 = Factory-Powered 15A GFI Convenience
Outlet
38 0 = None
