• Please read this manual
and save it with your original
sales receipt.
• Tools needed for assembly:
• Tools needed for assembly:
• Tools needed for assembly:
Phillips screwdriver and safety
Phillips screwdriver and safety
Phillips screwdriver and safety
• Use only with the included
• Use only with the included
• Use only with the included
Battery with Built-in Thermal
Battery with Built-in Thermal
Battery with Built-in Thermal
Fuse and a Power Wheels
Fuse and a Power Wheels
Fuse and a Power Wheels
12 Volt Charger with type 12V
12 Volt Charger with type 12V
12 Volt Charger with type 12V
connector (both included).
connector (both included).
connector (both included).
Owner's Manual
with Assembly Instructions
For Models L2170 and L7825
® ® ®
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Power Wheels L2170
Summary of Contents for Power Wheels L2170
- Page 1 ® ® ® 12 Volt Charger with type 12V 12 Volt Charger with type 12V 12 Volt Charger with type 12V connector (both included). connector (both included). connector (both included). Owner's Manual with Assembly Instructions For Models L2170 and L7825...
-
Page 2: Table Of Contents
• Use this vehicle ONLY outdoors. Most interior flooring can be repairs for a minimal charge. To find the authorized service center damaged by riding this vehicle indoors. Fisher-Price will not be ®... -
Page 3: Warnings And Cautions
ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - N ever modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. - U se of the wrong type battery or charger could cause a fire or explosion resulting in serious injury. - U se of Power Wheels ® components in products other than Power Wheels ® vehicles could cause overheating, fire or explosion. • T he battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the battery could result in serious injury. • Never allow children to charge the battery. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the battery. • Read the safety instructions on the battery. • Examine the battery, charger and their connectors for excessive wear or damage each time you charge the battery. If damage or excessive wear is detected, do not use the charger or the battery until you have replaced the worn or damaged part. • HOT motors. Handle carefully. RIDING HAZARD WARNING • Prevent Injuries and Deaths • Direct Adult Supervision Required. -
Page 4: Parts
PARTS • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. •... - Page 5 Assembly Tool Steering Wheel Assembly 12 Volt Charger 12 Volt Battery Part Not Shown: Label Sheet #8 x 1" Screw - 20 " Lock Nut " Washer - 4 Fasteners Shown Actual Size For your convenience, we included extra fasteners! Note: Tighten and loosen all screws with a Phillips screwdriver.
-
Page 6: Parts Picture
PARTS PICTURE Parts Not Shown " Lock Nut Windshield 2 Short Seat Belts Vehicle Steering Wheel Assembly Sport Bar Label Sheet Clip 12 Volt Charger #8 x 1" Screw - 20 Shovel Seat 12 Volt Battery " Washer Dashboard Long Seat Belt Assembly Tool L2170pr-0920 L2170pr-0920... -
Page 7: Battery Charging
BATTERY CHARGING ELECTRICAL HAZARD About Thermal Fuses WARNING Your Power Wheels 12 volt battery is equipped with a built-in ® thermal fuse. The thermal fuse is a self-resetting safety device which • Battery can fall out and injure a child if automatically “trips” and shuts down operation of the vehicle if the vehicle tips over. Always use battery retainer. -
Page 8: Assembly
ASSEMBLY The power indicator on the charger does not indicate the charge status WARNING of your battery. The power indicator allows you to see that there is power Children can be harmed by small parts, from the wall outlet. sharp edges and sharp points in the vehicle's unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle. Charger Connector •... - Page 9 PUSH Sport Bar Seat PUSH Ridge FRONT VIEW Slots • Fit the seat into the vehicle. Make sure the front edge of the seat is over the ridge in the vehicle. • Position the sport bar so that the screw holes near each end face Screws the rear of the vehicle.
- Page 10 PUSH Hood PUSH Hood Strap Windshield/Dashboard Assembly Slot Slot SIDE VIEW Hint: Remove the tape holding the hood to the vehicle. • Pull the hood straps down and then out to unfasten them from the button on each side of the vehicle. •...
- Page 11 Screws Hood Strap Hood Screws DASH VIEW SIDE VIEW Button • First, insert a screw through each side of the vehicle and into the • Lift and lower the hood closed. ends of the windshield/dashboard. Tighten the screws. • Pull the hood strap down and over the button on each side of the •...
- Page 12 Steering Column Steering Linkage Hole BOTTOM VIEW • Carefully turn the vehicle over. DASH VIEW • Fit the end of the steering column through the hole in the steering linkage. • Turn the vehicle upright. • Insert and “snap” the key into the hole in the dashboard. Lock Nut Assembly Tool •...
-
Page 13: Decoration
• After applying a label, rub the label firmly with a clean, dry cloth to make sure the label is adhered to your vehicle. Start at the center of a label, and smooth towards the outer edges to remove air bubbles. MODEL L2170 RIGHT SIDE VIEW... - Page 14 MODEL L7825 RIGHT SIDE VIEW LEFT SIDE VIEW L2170pr-0920 L2170pr-0920...
-
Page 15: Battery Installation
BATTERY INSTALLATION IMPORTANT! Use only a Power Wheels 12 volt lead-acid ® rechargeable battery with built-in thermal fuse. Use of any other battery will damage your vehicle. Make sure that you charge the battery for at least 18 hours using the enclosed Power Wheels ®... -
Page 16: Battery Care And Disposal
BATTERY CARE AND DISPOSAL Disposal Care If a battery leak develops, avoid contact with the leaking acid and • Your Power Wheels battery is a non-spillable, sealed lead-acid ® place the damaged battery in a plastic bag. See information below battery. -
Page 17: Safe Driving Rules
SAFE DRIVING RULES Teach Safety Rules to Children RIDING HAZARD While children can quickly develop the skill necessary to drive this vehicle, it is important to remember that their judgment skills are still WARNING very immature. Unsupervised driving by children can lead to serious injury. -
Page 18: Vehicle Operation
VEHICLE OPERATION IMPORTANT! Use this vehicle ONLY outdoors. Most interior flooring can be damaged by riding this vehicle indoors. Fisher-Price will not be ® responsible for damage to the floor if the vehicle is used indoors. As assembled, your vehicle is ready to roll in low speed (2 mph, maximum). -
Page 19: Cargo Bed
LIMITED WARRANTY CARGO BED Bumper-to-Bumper* Limited Warranty One year limited warranty from the date of purchase on the Power Wheels vehicle. ® Six month limited warranty on the 12 volt battery. For the original purchaser, this one year limited warranty covers the Power Wheels ride-on vehicle (purchased from Power Wheels ®... -
Page 20: Problems And Solutions Guide
PROBLEMS AND SOLUTIONS IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels Consumer Relations, toll-free at 1-800-348-0751 between 9 AM - 7 PM (EST) Monday through Friday ®... - Page 21 PROBLEM POSSIBLE CAUSE SOLUTION Vehicle was running but Loose wire or loose connectors Check all wires and connectors. Make sure the motor harness suddenly stopped connector is plugged into the battery, and that there are no loose wires around the motors. Tripped thermal fuse The built-in thermal fuse may "trip" and shut down operation of the vehicle if the vehicle is overloaded or the driving conditions too severe. Once a fuse has “tripped”, remove your foot from the pedal and wait approximately 25 seconds before operating the vehicle again. To avoid repeated automatic shutdowns, do not overload the vehicle by exceeding the 130 lbs. (59 kg) maximum weight capacity or by towing anything behind the vehicle. Do not drive up hills or run into fixed objects, which can cause the wheels to stop spinning while power is still being supplied to the motors. If a thermal fuse continually trips, contact your local Power Wheels ® authorized service center. Short run time (Less than Undercharged battery Charge the battery. A new battery should have been charged for 1 - 3 hours per charge) at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 14 hours after each use. Never charge the battery longer than 30 hours. Check all wires and connectors. Make sure the charger connector is plugged into the battery, and that the charger is plugged into the wall. Make sure power flow to the wall outlet is “ON”. Overcharged battery Do not charge the battery longer than 30 hours. If you suspect that your battery is damaged as a result of overcharging, contact ® your local Power Wheels authorized service center. They can test your battery for you.
- Page 22 PROBLEM POSSIBLE CAUSE SOLUTION Vehicle runs sluggishly Undercharged battery Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 14 hours after each use. Never charge the battery longer than 30 hours. Check all connectors. Make sure the charger connector is plugged into the battery, and that the charger is plugged into the wall. Make sure power flow to the wall outlet is “ON”. Battery needs charging Be sure to charge the battery after each use. Battery is old and will not accept Even with proper care, a rechargeable battery does not last forever. full charge Average battery life is 1 to 3 years depending on the vehicle use ® and use conditions. Replace the battery with a new Power Wheels 12 volt battery. Do not substitute parts. Vehicle is overloaded Make sure you do not overload the vehicle by allowing more than one rider at one time, by exceeding the 130 lb. (59 kg) maximum weight capacity, or by towing objects behind the vehicle. Driving conditions are too stressful Restrict your child's driving to areas that are generally level with gentle inclines or slopes. Vehicle runs in low speed, but High speed lock-out not disconnected The vehicle was pre-set to run only in low speed. To allow the does not run in high speed. vehicle to run in low and high speed, you must disconnect the High Speed Lock-Out. Follow the instructions on page 18 to Please note: The vehicle is remove the High Speed Lock-Out screw. designed to operate in low speed only in reverse . When the foot pedal is pressed Operation of vehicle in low speed It is possible that only one rear wheel may spin when both rear...
-
Page 23: Problem Possible Cause
PROBLEM POSSIBLE CAUSE SOLUTION ® Loud clacking or grinding noise Broken gears Contact your local Power Wheels authorized service center for from a motor-gearbox diagnosis and repair. Charger gets warm during use It is normal for some chargers to get No action required. warm during use and is not reason for concern. If your charger does not get warm during use, it does not mean that it is not working properly. Battery makes a sizzling or It is normal for some batteries to make No action required. gurgling noise when charging noise and swell slightly while charging and is not reason for concern. If your battery does not make noise or swell slightly during charging, it does not mean that it is not accepting the charge. L2170pr-0920 L2170pr-0920... - Page 24 ©2007 Arctic Cat Sales, Inc. ® TM Trademarks of Arctic Cat Inc. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2007 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
