4. Slide a sheet of paper down firmly between the edge guides
until it meets resistance. The printer loads the sheet and
begins printing automatically.
c
5. To stop printing temporarily, press the Pause button.
6. To end the self test, make sure the printer is not printing.
Press LF/FF to eject the sheet; then turn off the printer.
Here is part of a typical self-test printout:
Note:
If the self test did not print satisfactorily, see Chapter 3. If it prints
correctly, go on to the next section.
1-12
Setting Up the Printer
Caution:
Always close the printer cover while the printer is
printing. The printer cover helps the paper feed properly.
