OPERATOR'S MANUAL
MODEL GC-F4
Fabric Grass Catcher
P/N 9055
9
GRASS CATCHER GC-F4
1
2
8
11
10
4
7
6
5
3
PART 03213 Rev.2
SC301G

Advertisement

loading
Need help?

Need help?

Do you have a question about the GC-F4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Scag Power Equipment GC-F4

  • Page 1 OPERATOR'S MANUAL MODEL GC-F4 Fabric Grass Catcher P/N 9055 GRASS CATCHER GC-F4 SC301G PART 03213 Rev.2...
  • Page 2: Safety Instructions

    Check the catcher bag frequently and replace the bag if worn. REMEMBER - YOUR MOWER IS ONLY AS SAFE AS THE OPERATOR! FAILURE TO FOLLOW SAFE OPERATING PRACTICES MAY RESULT IN SERIOUS INJURY. This manual covers the operating instructions and illustrated parts list for: GC-F4 Grass Catcher Accessories...
  • Page 3 ADVANTAGE CUTTER DECK INSTALLATION INSTRUCTIONS Remove all packaging materials. Lay out the mounting hardware and the catcher assembly parts for easy access. Prepare the work area making sure that it is a clean, safe environment. Remove the discharge chute from the cutter deck. Retain all mounting hardware as the discharge chute must be reinstalled whenever the grass catcher is removed.
  • Page 4 ADVANTAGE CUTTER DECK INSTALLATION INSTRUCTIONS Install the mounting bracket (item # 4, Figure 3) to the cover weldment (item # 3, Figure 3) and secure with the hardware provided. Do not tighten the hardware. -NOTE- There are two (2) mounting brackets included with this grass cacther. The mounting bracket for Advantage cutter decks is longer than the mounting bracket for Velocity Plus cutter decks.
  • Page 5 VELOCITY PLUS CUTTER DECK INSTALLATION INSTRUCTIONS Install the grass catcher filler plate (item # 15, Figure 4, page 6) as shown In Figure 4. There are two (2) mounting slots in the grass catcher filler plate. Reference Figure 2 below for the correct mounting slot for the deck size this catcher will be mounted on.
  • Page 6 Grass Catcher GC-F4 for Advantage Cutter Decks SC301GA Figure 3 Ref. Part Number Description 481140 Catcher Bag 481135 Frame Weldment With Catcher Bag and Handle Assembly 461875 Cover Weldment With Decal 42211 Bracket, Mounting 483380 Decal, Danger 04001-20 Bolt, 3/8-16 x 1-1/2" Hex Head 04041-07 Flat Washer, 3/8"...
  • Page 7 Grass Catcher GC-F4 for Velocity Plus Cutter Decks Figure 4 Ref. Part Number Description 481140 Catcher Bag 481135 Frame Weldment With Catcher Bag and Handle Assembly 461875 Cover Weldment With Decal 42211 Bracket, Mounting 483380 Decal, Danger 04001-20 Bolt, 3/8-16 x 1-1/2" Hex Head 04041-07 Flat Washer, 3/8"...
  • Page 8 NOTES...
  • Page 9: Limited Warranty- Commercial Accessory

    The expense of delivering the accessory to the dealer for warranty work and the expense of returning it back to the owner after repair or replacement will be paid for by the owner. Scag’s responsibility in respect to claims is limited to making the required repairs or replacements, and no claim of breach of warranty shall be cause for cancellation or rescission of the contract of sale of any Scag machine.
  • Page 10 P/N 03213 Rev. 2 © 2007 REVISED 11/2007 SCAG POWER EQUIPMENT PRINTED 11/2007 DIVISION OF METALCRAFT OF MAYVILLE PRINTED IN USA...
