Page 2
WARNING FAILURE TO FOLLOW SAFE OPERATING PRACTICES MAY RESULT IN SERIOUS INJURY OR DEATH. • Read this manual completely as well as other manuals that came with your mower. • DO NOT operate on steep slopes. • Under no circumstances should the machine be operated on slopes greater than 20 degrees.
Section 1 GENERAL INFORMATION 1.1 INTRODUCTION A replacement manual is available from your authorized Scag Service Dealer or by contacting: Scag Power This manual has been prepared to provide the Equipment, Service Department at P.O. Box 152, Mayville, information you need to correctly assemble, operate, WI 53050.
Section 2 ASSEMBLY INSTRUCTIONS 2.1 ASSEMBLY INSTRUCTIONS - CUTTER DECK AND BLOWER COMPONENTS REMOVE SIDE BELT COVER REMOVE DISCHARGE CHUTE AND HARDWARE - NOTE - 1/4-20 x 1.375” Bolt Use the illustrated parts list as a part number Torque to 75 in. lbs. reference when following the assembly instructions.
Page 8
Section 2 -NOTE- Height Alignment Adjust the "Custom-Cut" baffle installed in the Tool cutter deck to the lowest position to enhance grass Height Alignment Tool catcher performance. 10. Bump mounting post (p/n 463627) to stiffner and clamp in place. Align edges. See Figure 2-5. Drill (.391 or 3/8"...
Page 9
Section 2 BACK SIDE IDLER PULLEY BLOWER PULLEY 3/8 ELASTIC STOP 3/8 LOCKWASHER 3/8 FLATWASHER 3/8 LOCKWASHER 3/8-16 x 1-1/4’’ BOLT p/n 453549 3/8 FLATWASHER SPINDLE FRONT SIDE 3/8 LOCKWASHER PULLEY IDLER PULLEY 3/8-16 x 1-1/4’’ BOLT 3/8 FLATWASHER p/n 461894 3/8 FLATWASHER Figure 2-9.
Section 2 Clamp p/n Drill Holes 429907 in place to frame Figure 2-10. Hopper Assembly 2.2 ASSEMBLY INSTRUCTIONS - HOPPER COMPONENTS 1. Aligning the mounting bracket with the fender, clamp the LH mounting bracket (p/n 429907) to the frame 3/8 Flatwasher as shown in Figure 2-10*.
Section 2 4. With help from an assistant, install the hopper 2. Using the weight support bar as a guide, identify the assembly to the machine and secure with the ring corresponding mounting holes used to secure the pins. See Figure 2-13. weight support bar to the front of the machine as shown in Figures 2-17.
Section 3 REMOVAL INSTRUCTIONS 3.1 GRASS CATCHER REMOVAL WARNING INSTRUCTIONS Prepare the machine so there is easy and safe access to Do not operate without discharge chute, mulch the work area. Park the machine on a flat, level surface kit, operator controlled discharge chute (OCDC), and apply the parking brake.
Section 5 GC-SVRXL BAG SUPPORT COMPONENTS GC-2B 2017 BSC...
Page 26
Section 5 GC-SVRXL BAG SUPPORT COMPONENTS Ref. Part No. Description 04090-02 Pop Rivet, 3/16 x .652 483589 Seal, GC Hood 424753 Retainer, Seal 04021-02 Nut, Center Lock 1/4-20 04021-10 Nut, Elastic Stop 5/16-18 462965 Bag Assembly 452675 Frame Weldment, Bag Support 04001-01 Bolt, 1/4-20 x 3/4"...
This warranty does not cover engines and electric starters, which are warranted separately by their manufacturer. Scag Power Equipment reserves the right to change or improve the design of any accessory without assuming any obligation to modify any accessory previously manufactured.
