Scag Power Equipment GC-STWC-61V Operator's Manual

Scag Power Equipment GC-STWC-61V Operator's Manual

Grass catcher
Hide thumbs

Advertisement

Quick Links

Download this manual
MODEL GC-STWC-61V
THIS MANUAL CONTAINS THE OPERATING
INSTRUCTIONS AND SAFETY INFORMA-
TION FOR YOUR SCAG ACCESSORY. READ-
ING THIS MANUAL WILL PROVIDE YOU
WITH MAINTENANCE AND ADJUSTMENT
PROCEDURES TO KEEP YOUR ACCESSORY
PERFORMING TO MAXIMUM EFFICIENCY.
THE SPECIFIC MODELS THAT THIS BOOK
COVERS ARE CONTAINED ON THE INSIDE
COVER. BEFORE OPERATING YOUR MA-
CHINE, PLEASE READ ALL THE INFORMA-
TION ENCLOSED.
PART NUMBER 03179

Advertisement

loading
Need help?

Need help?

Do you have a question about the GC-STWC-61V and is the answer not in the manual?

Questions and answers

Related Manuals for Scag Power Equipment GC-STWC-61V

Summary of Contents for Scag Power Equipment GC-STWC-61V

  • Page 1 MODEL GC-STWC-61V THIS MANUAL CONTAINS THE OPERATING INSTRUCTIONS AND SAFETY INFORMA- TION FOR YOUR SCAG ACCESSORY. READ- ING THIS MANUAL WILL PROVIDE YOU WITH MAINTENANCE AND ADJUSTMENT PROCEDURES TO KEEP YOUR ACCESSORY PERFORMING TO MAXIMUM EFFICIENCY. THE SPECIFIC MODELS THAT THIS BOOK COVERS ARE CONTAINED ON THE INSIDE COVER.
  • Page 2 This manual covers the operating instructions GC-STWC-61V with a serial number of B8400001 to B8499999 WARNING and illustrated parts list for:...

  • Page 3: Direction Reference

    A replacement manual is available from your authorized Scag Service Dealer or by contacting: Scag Power Equipment, Service Department at P.O. Box 152, Mayville, WI 53050. You may also contact us through our website at www.scag.com. The...
  • Page 4 3.1 ASSEMBLY INSTRUCTIONS FOR 61" CUTTER DECK -NOTE- Use the illustrated parts list as a part number reference when following the assembly instructions. 1. Remove all packaging materials. Lay out the mounting hardware and the catcher assembly parts for easy access. Prepare the work area making sure that it is a clean, safe environment.
  • Page 5 7. Install the blower assembly to the mounting bracket and secure with the mounting pin. See Figure 3-4. 8. Align the blower assembly with the discharge opening of the cutter deck. Tighten the hardware for the mounting bracket. See Figure 3-4.
  • Page 6 17. Install one 7/16-14 x 1-3/4" hex head bolt into each of the four mounting holes in the weight support bar, and through the matching holes in the caster support weldment. Secure this assembly to the front of the machine using the 7/16 - 1/2"...
  • Page 7 WARNING WARNING DO NOT OPERATE WITHOUT DISCHARGE CHUTE, MULCHING KIT, OR ENTIRE GRASS CATCHER INSTALLED 7. Re-install the side discharge chute to the opening on the cutter deck. Replace the two outside mounting bolts on the discharge chute with the clevis pins (p/n 04064-15) and rue cotter pins (p/n 04069-03).

  • Page 8: Maintenance Chart - Recommended Service Intervals

    5.1 MAINTENANCE CHART - RECOMMENDED SERVICE INTERVALS HOURS Break-In 8 20 40 100 200 500 (First 10) * Perform these maintenance procedures more frequently under extreme dusty or dirty conditions. GREASE FITTING ON BEARING HOUSING MAINTENANCE Procedure Check all hardware for tightness Inspect hose and adapter Check belt for proper alignment Inspect fabric bags...
  • Page 9 NOTES...
  • Page 10 GC-STWC-61V BLOWER HOUSING ASSEMBLY 2006 GC-STWC-61V Blower Assembly...
  • Page 11 GC-STWC-61V BLOWER HOUSING ASSEMBLY Ref. Part Number Description 04067-10 Pin, Ring 2-1/4" Long 481547 Lanyard, Deck Height Pin 04066-04 Quick Pin, 5/16" Dia. 04001-21 Bolt, Hex Head 3/8-16 x 1-3/4" 481377 Decal, Blower 482080 Decal, Rotating Blower 481428 Grip, Blower Lever...
  • Page 12 GC-STWC-61V" BLOWER MOUNTING COMPONENTS UNDER SIDE OF VELOCITY-PLUS CUTTER DECK SHOWN RIGHT SIDE OF CUTTER DECK SHOWN 2006 GC-STC-V BMC...
  • Page 13 GC-STWC-61V" BLOWER MOUNTING COMPONENTS Ref. Part Number Description 483227 Belt Cover, GC-61V 04029-04 Wingnut, Plastic 3/8" Small 483223 Cap, Square Vinyl 04021-08 Nut, Elastic Stop 1/4-20 461723 Adapter, Blower GC-STC, includes item #7 04040-14 Flatwasher, 1/4-.312 x .750 x .065 48137-04 Rubber Strap 7-3/4"...
  • Page 14 GC-STWC-61V BUCKET SUPPORT COMPONENTS (UPPER)
  • Page 15 GC-STWC-61V BUCKET SUPPORT COMPONENTS (UPPER) Ref. Part Number Description 423302 Screen, Catcher Hood 04090-02 Pop Rivet, 3/16 x .652 04041-19 Flatwasher, 3/16-.196 x .469 x .048 04001-32 Bolt, Hex Head 3/8-16 x 1-1/4" 04041-01 Flatwasher, 3/8-.391 x .938 x .105 461408 Hood Assembly, GC-STT (includes items 1, 2 &...
  • Page 16 GC-STWC-61V BUCKET SUPPORT COMPONENTS (LOWER) "A" TO "A" STC 2002 BSC...
  • Page 17 GC-STWC-61 BUCKET SUPPORT COMPONENTS (LOWER) Ref. Part Number Description 04090-02 Pop Rivet, 3/16 x .652 482321 Seal, Hood 423262 Tube, Upright 04041-07 Flatwasher, 3/8-.391 x .938 x .105 04021-09 Nut, Elastic Stop 3/8-16 04020-04 Nut, 3/8-16 04021-05 Hex Lock Nut, 3/8-16 04067-07 Pin, Ring 1/2 x 2-1/4"...
  • Page 18 GC-STC DECALS 482871 482871 481327 483037 482275 MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING PATENTS: 4,487,006 4,885,903 4,920,733 4,967,543 4,991,382 4,998,948 5,042,239 5,118,617 5,133,176 5,826,416 5,832,708 5,865,018 6,192,666 6,766,633 6,892,519 PATENTS PENDING 483044 481377 482080 482080...

  • Page 19: Limited Warranty- Commercial Accessory

    This warranty does not cover engines and electric starters, which are warranted separately by their manufacturer. Scag Power Equipment reserves the right to change or improve the design of any accessory without assuming any obligation to modify any accessory previously manufactured.
  • Page 20 © 2005 PART NO. 03179 SCAG POWER EQUIPMENT PRINTED 8-2005 DIVISION OF METALCRAFT OF MAYVILLE, INC. PRINTED IN USA WWW.SCAG.COM...
