SECTION 10
10-1 PARTS LIST
[CHARGE UNIT]
REF. NO. ODER NO.
R1 7010007550 RESISTOR
R2 7010007100 RESISTOR
J1 6510021470 CONNECTOR
DS1 5040001390 LED
EP1 0910053820 PCB
MP1 8930051340 2338 TERMINAL
MP2 8930051340 2338 TERMINAL
[CHASSIS UNIT]
REF. NO. ODER NO.
MP1 8010018620 2447 case (A)
MP2 8110007450 2447 cover
MP3 8930039620 Leg cushion (A)
MP4 8930055020 2480 spacer
MP5 8930055030 2480 BC-spacer
MP6 8810008660 Screw B0 M 3 x 8 NI-ZU (BT)
Screw abbreviations B0, BT:Self-tapping
BC-146 OPTIONAL DESKTOP CHARGER INFORMATION
DESCRIPTION
ERG3SJ680H
PSD1/4V 1 k
HEC0470-01-230
TLG124A
B 5650
DESCRIPTION
NI-ZU :Nickel-Zinc

10-2 DISASSEMBLY INFORMATION

QTY.
1
1
1
MP5 A
1
1
1
1
MP1
QTY.
1
1
4
1
1
1
MP2
MP3 A
10 - 1
A
MP4
A
A
MP6 A
A
MP3 NOTE:
MP1 B
MP2 B
CHARGE unit
A
MP3
MP3 A
A :CHASSIS UNIT
:CHARGE UNIT
B
