Table 1.
Button
Off (dark)
Green, steady
Red, steady
Amber, flashing
Green, flashing
These capabilities provide features that are similar to typical Direct Station Selection/Busy Lamp Field (DSS/BLF)
modules but are not intended to be directly comperable to traditional DSS/BLF modules. The Cisco Unified IP Phone
Expansion Module 7916 is not an operator or attendant console. The primary function of this module is to provide the
Cisco Unified IP Phone 7962G, 7965G, and 7975G models with additional keys for features such as speed dial or
directory numbers. The illuminated buttons provide ease of line status, making the Cisco Unified IP Phone
Expansion Module 7916 an ideal call-coverage tool.
The two illuminated page buttons beneath the display of the Cisco Unified IP Phone Expansion Module 7916 allow
you to shift between the first and second pages of 12 buttons, providing access to all 24 keys, 12 at a time (Table 2).
Table 3 lists the features of the Cisco Unified IP Phone Expansion Module 7916.
Table 2.
Button
Off (dark)
Green, steady
Amber, flashing
Table 3.
Feature
Graphical display
Directory-number and feature buttons
Page buttons
Sleep or inactivity mode

Software Requirements

Table 4 lists the software requirements for the Cisco Unified IP Phone Expansion Module 7916.
Table 4.
Specification
Phone software requirements
Call-control compatibility
Signaling protocols
© 2009 Cisco Systems, Inc. All rights reserved. This document is Cisco Public Information.
Illuminated Buttons
Line Status
Line available
Line in use
Line in use by someone else
Line ringing
Call is on hold
Illuminated Page Buttons
Page Status
Page not in focus
Page in focus
Page not in focus with one or more alerting or on-hold calls present on page
Features and Description
Description
4.3" graphical (TFT) color display, 16-bit color depth, 480 x 272 effective pixel resolution, with backlight.
The display also supports localization requiring double-byte Unicode encoding for fonts.
The module has 12 physical buttons (24 with page key).
The two Page buttons are used to access each page of 12 buttons and provide phone status.
When Cisco Unified IP Phone 7965G or 7975G models are in power-saving sleep or inactivity mode, the
Cisco Unified IP Phone Expansion Module 7916 is also in sleep or inactivity mode. In addition to the
Display button, any button on the Cisco Unified IP Phone Expansion Module 7916 that is pressed will
cause the displays to awaken. The inactivity period is configured by the system administrator.
Cisco Unified IP Phone Expansion Module 7916 Software Requirements
Description
8.3(5) and later
Cisco Unified Communications Manager 4.2(3) SR3a, 4.3(2), 5.1(3)b, 6.1(1), 7.0, 7.1 and later; Cisco Unified
Communications Manager Express 4.3/7.0 and later. Cisco Unified Survivable Remote Site Telephony
(Unified SRST) 4.1 (IOS 12.4.15T) and later.
Skinny Client Control Protocol (SCCP) Software 8.3(5) and later
Session Initiated Protocol (SIP) Software 8.4(1) and later
Data Sheet
Page 3 of 7
