CTEK 1027 User Manual page 3

INSTAllINg ThE ChARgER IN ThE VEhIClE
Install the charger on a surface where it can be properly fixed and where the charger is not exposed
to fuels, oils or splashes of dirt. Mount the charger with screws intended for the surface and attach
it with one screw in each of the four holes in the corners of the charger. See picture 1. Mount the
charger with M4 or ST4.2 screws with maximum torque of 2Nm.
Target battery –
Supply source –
Target battery +
Supply source +
M4 or ST4.2
Temperature
sensor
Max torque 2Nm
Picture 1
WARNINg
Due to high risk of short circuit, batteries should not be connected to power cords when installing
the charger.
3
