Example System Setups

Note: If the AmpliCenter is used
®
with the PagePac Plus
Controller, refer to the
Controller Installation and Use
Guide for detailed instructions.
Figure 11 illustrates the interconnection between the AmpliCenter and the
Controller, if used. Figure 12 illustrates the interconnection of two or more
AmpliCenters.
105 - 120 VAC
210 - 2 0 VAC 4
50 - 60 Hz
Figure 11. AmpliCenter Interface with PagePac Plus Controller
FIRST AMPLICENTER
AC POWER
CONNECTION
NEXT AMPLICENTER
AC POWER
CONNECTION
Figure 12. Series AmpliCenter Without Controller
105 - 120 VAC
210 - 240 VAC TO
70V OUT PAGING IN
50 - 60 Hz 0 dBm CONTROLLER
OUT UNIT
LOW FREQ
+
CUT-OFF -
C1
PAGING
CONNECTION
NEXT AMPLICENTER
105 - 120 VAC
TO
70V OUT PAGING IN
210 - 240 VAC
0 dBm CONTROLLER
50 - 60 Hz
UNIT
OUT
LOW FREQ
+
CUT-OFF -
C1
TO NEXT
AMPLICENTER
9
MUSIC
INPUT
PAGE
MUSIC IN
INPUT
TO HOST TEL.
SYSTEM
(USE EITHER
METHOD)
TO HOST TEL.
SYSTEM
TO SPEAKERS
MUSIC
INPUT
PAGE
MUSIC IN
INPUT
SET TO
DRY LOOP
600
TO SPEAKERS
