PAGE PORT PREAMP/EXPANDER
FEATURES:
BRUSHED STAINLESS STEEL PLATE
EMBOSSED MARKINGS FROM 0 TO 10
WALL MOUNTABLE
COMES WITH SINGLE GANG SURFACE MOUNT BOX
DESCRIPTION:
The V-1094A is a solid-state audio preamplifier capable of driving150 Valcom one-way speaker/amplifier
assemblies. The V-1094A features a stainless steel plate with embossed numbers and fits a single gang electrical
wall box. the page port preamp/expander will interface 600 ohm type page ports to up to 150 Valcom amplified
speakers or expand the number of Valcom amplified speakers on a zone by 150.
IMPEDANCE:
Input: 600 ohms
Output: 8 ohms
POWER REQUIREMENTS:
Voltage: -21 to -26 Vdc
Idle Current: 12 mA
Operating Current: 15 mA
FREQUENCY RESPONSE:
80 Hz to 10 kHz +/- 3 dB
GAIN:
+ 8 dB maximum (Iinto 8 ohm load)
5614 Hollins Road
Roanoke, Virginia 24019
E-Mail: support@valcom.com
MODEL V-1094A

SPECIFICATIONS:

HOUSING AND FINISH:
Brushed stainless steel single gang plate
with raised number dial scale; skirted
black knob and position indicator.
MOUNTING:
The V-1094 can be mounted in wall or on
surface using single gang electrical box.
DIMENSIONS AND WEIGHT
4.44" (11.28 cm) H x 2.75" (6.99 cm) W x
2.88" (7.32 cm) D
Weight: 0.9 lb (.41 kg)
Phone: 540-563-2000
www.valcom.com
TECHNICAL
SPECIFICATIONS
:
Fax: 540-362-9800
