FRONT PANEL

POWER
Electronic POWER switch
"Easy touch" - type.
Turn on the machine
with a single light touch.
To turn off the machine
you must press and hold
down the POWER key
approx. 3 seconds.
6
POWER
VOCAL INTONATION PROCESSOR
INPUT PITCH/CORRECTION
SIGNAL LED DIGITAL LOCK
Present Input signal. Shows when the Intonator is
@ -22dBFS locked to an external digital
signal. Blinking LED indicates
PEAK LED "unacceptable" or "no clock".
Indicates Input level
overload. MIDI INPUT
@ -3dBFS Indicates incoming MIDI data.
LEVEL KNOB MIDI OVERRIDE LED
Adjusts the Input level. This LED indicates that analog
controls (such as Attack,
METER KEY Amount, Window) have been
Switches the changed via MIDI and are
Pitch/Correction different than their front panel
display to show the settings.
Input level momentarily. The OVERRIDE LED will go
out when all parameters
match the front panel controls.
INPUT
PPM METER
STATUS SCALE FLAT
Peak
DIGITAL LOCK
Signal
MIDI INPUT
MIDI OVERRIDE
5
KEY -200 100
20
Keyboard
# b
-6 26
C D
dB
ANALOG IN
PITCH/CORRECTION
PITCH SHARP
75 50 40 30 20 10 10 20 30 40 50 75 100
# b # b # b
E F G A
KEY/SCALE INDICATOR
Shows the current key and
displays Input Pitch in Chromatic
and Manual modes. When in
"Setup mode" this area indicates
current page number.
PITCH/CORRECTION DISPLAY
In Scale mode the amount of
pitch correction applied is
displayed.
In Setup mode various
parameters are displayed:
Input Source, Clock Source,
Dither, MIDI, Master Tune etc.
KEYBOARD
Shows: - Current scale tones
- Current Input pitch
Gives: - Tuning notes
- Custom scale editing.
- Allows you to force
Input signal to a
specific tone when
used in Manual mode.
PITCH
CORRECTION
200+ CENT
# b
B
