X8SAX/C7X58 User's Manual
PC Health Monitoring
CPU Monitoring
•
Onboard voltage monitors for CPU core, Memory Voltage, Chipset Voltage,
+1.8V, +3.3V, +3.3V standby, +5V, +5V, Standby, VBat and ±12V
•
CPU 6-Phase-switching voltage regulator
•
CPU/System overheat LED and control
•
CPU Thermal Trip support
•
Thermal Monitor 2 (TM2) support
Fan Control
•
Fan status monitoring with firmware 4-pin PWM (Pulse Width Modulation)
fan speed control
•
Low noise fan speed control
System Management
•
PECI (Platform Environment Configuration Interface) support
•
System resource alert via
•
Doctor III, Watch Dog, NMI
•
I C temperature sensing logic
2
•
Chassis Intrusion Header and Detection
•
Pb Free
CD Utilities
•
BIOS flash upgrade utility
•
Drivers and software for Intel® X58 Express chipset utilities
Dimensions
•
ATX form factor, 12" x 10" (304.8 x 254.0 mm)
Doctor III
1-8
