Motherboard Features

CPU
® Core™ i7 / i7 Extreme Edition, and Intel® Xeon® 5500/3500 series
•
Single Intel
processors in an LGA1366 socket
Memory
•
Six 240-pin, DDR3 SDRAM DIMM sockets with support for unbuffered ECC (if
supported by CPU) or non ECC 1333/1066/800 MHz memory.
•
Supports non ECC 1600 MHz XMP memory when an Extreme Edition CPU is
installed (This feature is supported on the C7X58 motherboard only, see pages
2-10, 3-3, 3-4 and 4-11 for more information.)
•
Supports 3-channel memory bus
•
DIMM sizes of 256 MB, 512 MB, 1 GB, 2 GB, and 4 GB are supported
Chipset
•
Intel® X58 Express Chipset (IOH)
•
Intel ICH10R (South Bridge)
•
Intel PXH/V (I/O Bridge) for PCI-X slots (X8SAX only)
Expansion Slots
•
Two (2) PCI-Express x16 Gen2 slots (Slot 6/Slot 4)
•
One PCI-Express x4 in x8 slot (Slot 5)
•
Two (2) PCI-X 133/100 MHz slots (Slot 1/Slot 2) (X8SAX only)
•
One (1) 32-bit PCI 33MHz slot (Slot 3)
Audio
•
The HD ALC883 Audio Controller supports 7.1 channel High Definition audio
interface
•
One HD Audio connector on the IO backplane supports 8-channel (7.1) audio
with Line-in/Line-out/Microphone built-in
•
One S/PDIF connector on the IO backplane supports Digital Audio/Video In-
terface
•
One additional onboard audio header (Audio FP) and a CD input header (CD-
In) for front access
Graphics
•
Support for multiple PCI-Express Graphics cards (Gen 2 or Gen 1)
® CrossFireX™ Technology
•
Supports ATI
•
Supports nVidia
® SLi™ Technology (C7X58 only)
