Summary of Contents for Kramer VM-4HDCP
-
Page 1: User Manual
Kramer Electronics, Ltd. Preliminary USER MANUAL Model: VM-4HDCP 1:4 DVI Distributor... -
Page 2: Table Of Contents
Figure 1: VM-4HDCP 1:4 DVI Distributor Figure 2: Connecting a VM-4HDCP 1:4 DVI Distributor Tables Table 1: Front Panel VM-4HDCP 1:4 DVI Distributor Features Table 2: Rear Panel VM-4HDCP 1:4 DVI Distributor Features Table 3: Technical Specifications of the VM-4HDCP 1:4 DVI Distributor... -
Page 3: Introduction
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products 2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com 3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com... -
Page 4: Quick Start
Getting Started Quick Start This quick start chart summarizes the basic setup and operation steps. KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 5: Overview
1:4 distribution amplifier for DVI-D (Digital) signals . Since high-resolution DVI signals are very sensitive to cable quality and to PCB layout, the VM-4HDCP uses a uniquely designed PCB which includes all buffering, conditioning and amplifying circuitry to provide four high-level output signals. -
Page 6: About Hdcp
) is a data-structure, provided by a display, to describe its capabilities to the source. The EDID enables the VM-4HDCP to “know” what kind of monitor is connected to the output. The EDID includes the manufacturer’s name, the product type, the timing data supported by the display, the display size, luminance data and (for digital displays only) the pixel mapping data. -
Page 7: Figure 1: Vm-4Hdcp 1:4 Dvi Distributor
Your VM-4HDCP 1:4 DVI Distributor Figure 1: VM-4HDCP 1:4 DVI Distributor... -
Page 8: Table 1: Front Panel Vm-4Hdcp 1:4 Dvi Distributor Features
Your VM-4HDCP 1:4 DVI Distributor Table 1: Front Panel VM-4HDCP 1:4 DVI Distributor Features Feature Function POWER Switch Illuminated switch for turning the unit ON or OFF ACTIVE LED Lights when the input is active; blinks when the input is not valid... -
Page 9: Installing The Vm-4Hdcp In A Rack
Installing the VM-4HDCP in a Rack Installing the VM-4HDCP in a Rack This section provides instructions for rack mounting the unit. -
Page 10: Connecting A Vm-4Hdcp 1:4 Dvi Distributor
Connecting a VM-4HDCP 1:4 DVI Distributor Connecting a VM-4HDCP 1:4 DVI Distributor To connect the VM-4HDCP as illustrated in the example in Figure 2, do the following: 1. Connect a DVI source (for example, a computer) to the INPUT connector. -
Page 11: Acquiring Edid
Connecting a VM-4HDCP 1:4 DVI Distributor Figure 2: Connecting a VM-4HDCP 1:4 DVI Distributor Acquiring EDID The VM-4HDCP initially operates with the default EDID. This means that you can turn ON the power before connecting any of the acceptors or the source. -
Page 12: Restoring The Default Edid
1 After cycling once through all the outputs, the blinking will resume and you will have to start this procedure again to choose the desired output 2 Specifications are subject to change without notice 3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com KRAMER: SIMPLE CREATIVE TECHNOLOGY... - Page 13 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
- Page 14 For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com, where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
