E - 6
Adjusting the Monitor
There are 4 keys & one wheel for user's control that includes Power,
Auto, Exit, Enter and a wheel. The following descriptions are the intro-
duction of these keys & fly wheel.
1. Power: Turn the power on or off.
2. Auto: Adjust vertical position, phase, horizontal position and
pixel clock automatically.
3. Exit: Back to main menus ; Entering "save menu"; Exit OSD
menu without saving. Hot key for Audio volume adjustment.
4. Enter: Enter main/sub menus ; select items ; save menu.
5. Fly-wheel: Left/right adjustment. Hot key for Brightness/Con-
trast adjustment.
Exit
Auto
Enter
Fly-wheel
Page 16
Adjusting the Monitor
Power Indicator
Power
01/02/28, 17:40
