Adjusting the Monitor

Adjustable Items
Luminance
Contrast
Adjusts the contrast.
Brightness
Adjusts the brightness.
Geometry
Hor. Position
Adjusts a displaying position in horizontal direction.
Ver. Position
Adjusts a displaying position in vertical direction.
Phase
Adjusts a phase when horizontal noise is displayed on the screen.
Also used when characters are blurred or not sharply displayed.
Pixel Clock
Expands or contracts the screen.
Color Adjustment
(9300K)
Selects the pre-set color (9300K).
(6500K)
Selects the pre-set color (6500K).
(5800K)
Selects the pre-set color (5800K).
(User)
Adjusts the color proportion for red, green and blue.
LCD1700M
Black
7
9
–continued
