Specifications - NEC MultiSync LCD1700M+ Installation Manual

E - 14

Specifications

Monitor
Specifications
Picture Tube Diagonal:
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal Video:
Display Colors Analog input:
Synchronization Horizontal:
Range Vertical:
Resolutions Supported
Resolution based on horizontal and
vertical frequencies only
Active Display Area Horizontal:
(Full Scan) Vertical:
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature:
Humidity:
Storage Temperature:
Humidity:
Speakers Practical Audio Output
NOTE: Technical specifications are subject to change without notice.
MultiSync LCD
1700M+
Monitor
17.0 inch
17.0 inch
1280x1024
ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Over 16.7 Million Colours
31 kHz to 81.1 kHz
56 Hz to 76.6 Hz
720 x 400 @ 70 Hz
640 x 480 @ 60 to 75 Hz
800 x 600 @ 60 to 75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60 to 75 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60 to 76 Hz ..........
338 mm/13.3 inches
270 mm/10.6 inches
AC 100 - 240 V, 50-60 Hz
1.2 A @ 100-120 V / 0.5 A @ 220-240 V
422 mm (W) x 451 mm (H) x 208 mm (D)
16.6 inches (W) x 17.8 inches (H) x 8.2 inches (D)
7.5 kg
16.5 lbs
5° C to + 35° C
20% to 80%
Feet:
0 to 12,000 Feet
-20° C to +60° C
5% to 85%
Feet:
0 to 40,000 Feet
1.0 W + 1.0 W
Page 24
Specifications
Notes
Active Matrix; Thin Film
Transistor (TFT), Liquid
Crystal Display (LCD),
0.264mm
dot pitch; 200cd/m 2 , white
luminance; 350:1 contrast
ratio, typical.
Depends on display card
used.
Automatically
Automatically
Some systems may not
support all modes listed.
NEC-Mitsubishi
Electronics Display cites
recommended resolution at
60 Hz for optimal display
performance.
Dependent upon signal
timing used, and does not
include border area.
