E - 2
Hardware Installation
To attach the MultiSync monitor to your system, follow these instruc-
tions:
1. Make sure that the computer and monitor's power are both turned
off. Please follow the steps to install your LCD monitor.
a. Place monitor face down on a non-abrasive surface. Take off
the rear cover, then the base cover.
b. Connect the power cord to your LCD monitor. Then connect
the audio cable into the Audio Input of the monitor. Reattach
base cover.
Bundle cables here.
c. Put rear cover back.
d. Plug the 15-pin Mini D-SUB cable into the signal connector
of the computer.
Page 12
Hardware Installation
