Built for Live Cell Imaging
Research
Inverted System Microscope
IX71/IX81
IX2 Series

Advertisement

loading
Need help?

Need help?

Do you have a question about the IX71 and is the answer not in the manual?

Questions and answers

Related Manuals for Olympus IX71

Summary of Contents for Olympus IX71

  • Page 1 Dr. Kazuo Kurokawa, Department of tumor virology, Research institute for microbial diseases, Osaka university (P24 below, Kaede-Crk II protein expressed in a HeLa cell) Built for Live Cell Imaging • OLYMPUS CORPORATION is ISO14001 certified. • OLYMPUS CORPORATION is FM553994/ISO9001 certified.
  • Page 2 Olympus has equipped its IX2 series microscopes with the new UIS2 optical system precisely to meet those demands. With high S/N ratio, compensation for chromatic aberration over a...
  • Page 3 PLANAPO60XO and UPLSAPO100XO have outstanding N.A., 1.42 and 1.4 respectively, suitable for fluorescence imaging and bright- UIS2 objective for the IX71/81 achieves flat, high transmittance from The UPLSAPO series is the highest class UIS2 objectives, whose field observation as well. In addition to their high fluorescence S/N...
  • Page 4 Two-tier multi-port design ensures input/output flexibility. Optical Port system Improved near-infrared transmission Two-tier optical design is also near-IR compatible With the introduction of the new UIS2 optical system, the IX2 series The input/output of a parallel pencil of rays and the multiple port IX2 Two-tier optical path offers improved IR transmittance for the side port, back port and structure for gaining the primary image are designed internally in the...
  • Page 5 Better S/N ratio delivers brighter, higher-contrast the objectives outer portion Olympus mirror units absorb more than 99% of this stray light High S/N ratio objective with reduced autofluorescence images in fluorescence observation.
  • Page 6 This unique field stop allows the user to control the area of U-TV0.63XC, U-TV1X-2 , U-TV1XC] The Olympus lineup for fluorescence illumination equipment meets a wide variety of needs and removable aperture and field stops. fluorescence excitation anywhere inside the visual field. For...

  • Page 7: Differential Interference Contrast

    (N.A. 0.55), the LWUCD condenser accommodates most source is unified in a polarizer (condenser a lot of inherent contrast. Olympus provides three DIC systems with control. Three high numerical aperture top incubation chambers and T-Flasks. The 5-position turret provides side);...
  • Page 8 UPLSAPO UPLSAPO 4X 0.16 26.5 — The Olympus Relief Contrast system provides a high contrast, UPLSAPO 10X2 26.5 0.17 3-D image similar to DIC for specimens mounted in plastic vessels. UPLSAPO 20X 0.75 26.5 0.17...

  • Page 9: Basic Characteristics

    The objective type and its magnifications can easily be recognized through this In addition to maximizing rigidity of IX2 microscope frame, Olympus glass stage insert. simplified or shortened mechanical structures from the focusing handle to the revolving nosepiece, thereby achieving to minimize the focus drift.
  • Page 10 Motorized system for live cell imaging. Motorized Units Controlling functions via PC, handset or operating buttons on the microscope body Motorized universal condenser/ Motorized shutter/IX2-SHA Functions of IX81 control software /IX2-BSW IX2-LWUCDA2 Can be mounted in both transmitted and Nearly every operating function on the IX81 can be allocated to operation reflected light paths.
  • Page 11 Maintaining long-term stability for live cell observation. Live Cell Imaging System Live cell imaging system Accessories to improve stability in long-duration observations Focus drift compensation function for [ CO incubators/MIU-IBC-I, MIU-IBC-IF ] [ Incubators ] This box type incubator keeps the microscope temperature stable Highly precise incubator control keeps the environment inside a time-lapse experiments.
  • Page 12 • Olympus' original high N.A. objectives make it easy to produce an evanescent wave field. So little light is leaked that a high-contrast image can be obtained against a dark background.
  • Page 13 Conventional fluorescence observation TIRFM observation Microscopy) system with arc lamp source The Olympus Disk Scanning Unit (DSU) offers confocal images using a white light, arc excitation source and CCD camera. The Featuring the Olympus-developed total internal reflection heart of the system is a unique slit disk pattern, that offers excellent illumination system and slit mechanism to provide evanescent wave light throughput and thinness of optical Sectioning.
  • Page 14 • A specified area of the cell can be exposed to UV light while of free space between the microscope frame and the primary observing the targeted cell by fluorescence or transmitted (DIC) image plane found on all Olympus Research Upright and Inverted method. Microscopes.
  • Page 15 Long working distance universal IX2-LWUCD 5 positions for optical devices (3 positions for ø30 mm and 2 position for ø38 mm), aperture iris diaphragm adjustable, N.A. 0.55 / W.D. 27 mm IX71+fluorescence illuminator combination dimensions (unit: mm) IX71+L-shaped fluorescence illuminator dimensions (unit: mm)
  • Page 16 20/80% prism unit for lower back port with 100% prism C-mount camera C-mount camera C-mount camera C-mount camera To consult with local Olympus subsidiary camera Lower back port port tube with port tube with port tube with port tube with...
