Specifications

Technical:
Inputs Tx (Each): (1) HDMI, (1) 3.5mm Stereo (as either input or output)
➔
Outputs Tx (Each): (1) CAT5e/6
➔
Inputs Rx (Each): (1) CAT5e/6
➔
Outputs Rx (Each): (1) HDMI, (1) 3.5mm Stereo (as either input or output)
➔
HDMI and HDCP Licensing: Fully licensed and compatible with all HDMI
®
➔
and HDCP techologies
Link and Range: 1080p/60, 1920x1200, 1080i/60, 720p, 1080p/24;
➔
up to 250 ft. when used with KD-CAT6STP1X cabling, up to 200 ft. when used
with CAT5e/6 cabling. 4K resolution up to 120'.
Lossless Compressed Digital Audio Support: Dolby
➔
and DTS -HD Master Audio
™
DDC Signal (Data): Input DDC Signal: 5 Volts p-p (TTL)
➔
HDMI Video/Audio Signal: Input Video Signal: 1.2 Volts p-p
➔
HDMI Connector: Type A, 19 Pin Female
➔
RJ45 Connector: Shielded Link Connector
➔
Control Extension Connector: 3.5mm Stereo Jack
➔
I2C Communication: EDID and HDCP bi-directional transparency
➔
from Display to Source
CEC Support: To the main input and output HDMI channel.
➔
TrueHD, Dolby Digital Plus
® ®
general
Regulation: CE, RoHS, WEEE
➔
Enclosure: Black Metal
➔
Product Dimensions (Each): L = 6" W = 4.1" H = 1.2"
➔
Shipping Carton Dimensions: L = 7.48" W = 6.54" H = 5.2"
➔
Product Weight (Each): 1 lb
➔
Shipping Weight: 3 lbs
➔
Power: UL Certified Power Supply – 5V / 2A, 110-240 VAC, 50-60 Hz
➔
Power Consumption: Tx - 2.5 Watts, Rx - 5 Watts
➔
Accessories
(2) 5V 2A DC Power Supply (KD-CATHD250Lite)
➔
» KD-CATHD250Lite requires power on both Tx and Rx units
(1) 12V 2A (KD-CATHD250POH)
➔
» KD-CATHD250POH only requires power on the Tx units,
which extends power to the Rx unit
(2) Mounting Brackets
➔
(2) Locking HDMI Cable Clips
➔
(1) Grounding Wire
➔
