Kramer VP-725DSA User Manual page 10

Has multi-standard video support; supports VESA standards; HDTV
standards and other popular resolutions on the input. Does not support
HDCP (High bandwidth Digital Content Protection) on the DVI
Features a Video Group Mode
simultaneously and independently (except for DVI: once a DVI input is
selected in the Scaler Mode, that DVI input selection cannot be changed
in the Video Group Mode)
Features an Audio Group Mode
a balanced stereo audio output on a terminal block connector for each
group. In addition, in the AV Group you can select the audio-follow-video
input from each group for switching, and in the Master AV Group you can
convert the selected video input (one of 18) to the SCALED OUTPUTS,
and also route the selected audio input (one of 18) to the MASTER OUT
terminal block connector
An independent Master Audio output that has a rich set of ProcAmp
features, including bass and treble controls (via the MENU and LCD status
display (and OSD when appropriate)), RS-232 and the infra-red remote
control transmitter
Audio breakaway option (to switch audio independently from video) or
Audio-follow-video
Adjustable volume on each input and output
A microphone input that can be used by mixing, switching or talk-over
Includes a front panel lock, as well as a separate OSD lock
In addition to providing an up- or down- scaled output of the selected (one of
18) inputs, also functions as 4x1 switchers for each video group (2x1 for DVI)
Has ProcAmp
Lets you freeze the image at any instant
Lets you select the output colorspace (RGB or YPbPr)
1 A method of security encryption (developed by Intel and Silicon Image)
2 An HDCP source would show up as a very snowy, noisy picture at the output
3 Selects the video input from each group: CV, YC, Component, VGA, DVI for switching to its local (group) output
4 Converts the selected input (one of 18) to the SCALED OUTPUTS
5 Selects the audio input from each group for switching
6 Routes the selected audio input (one of 18) to the MASTER OUT terminal block connector
7 Processing amplification enables adjustment of different video and audio signal parameters
4
Overview
3
7
controls for the scaler output
and a Scaler Mode
5
and a Master Audio Group Mode
KRAMER: SIMPLE CREATIVE TECHNOLOGY
2
4
. These modes function
6
, with
1
