Figure 2 and Table 2 define the rear panel of the VP-725DSA:
1 Only one of the three buttons can be ON, or all three buttons can be OFF (pressing a button will select that button, and turn
OFF the previously selected button. If the selected button is pressed, it will turn it OFF)
2 Selecting OUT when the Audio Group button illuminates, lets you select the group (scrolling through CV, YC, VGA,
Component and DVI, displaying the selection on the LCD (and OSD when appropriate) using the UP and DOWN buttons
3 Note, that once a DVI input is selected in the Scaler Mode, that DVI input selection cannot be changed in the Video Group
Mode
8
Your VP-725DSA Presentation Switcher / Scaler
Press this button and adjust using the –/+ buttons. The level is displayed in the
LCD Display and OSD
G Shows which video input from each group is selected for switching, and
ROUP
facilitates the selection of an alternative video input from each group
G Selects the audio (breakaway mode) input from each group for switching
ROUP
When selected shows which of the 18 video inputs has been selected to be
scaled at the SCALED OUTPUTS, and facilitates the selection of an alternative
video input for scaling
A When selected routes the selected audio input (one of 18) to the
UDIO
MASTER OUT terminal block connector
Function
