Toa C-CV14-CS Specifications

COMPACT COLOR CAMERAS
Lens is optional
Lens included
DESCRIPTION
TOA's compact color cameras represent new
approaches to high-performance and high-resolution
cameras for CCTV applications, each camera having
specific features and functions.
Indoor type: C-CV14-CS (lens is optional)
C-CV14-2 (with 2X varifocal lens)
C-CV24-2 (with 2X varifocal lens)
Outdoor type: C-CV44-3 (with 2X varifocal lens)
FEATURES
●
Easy power requirements
TOA compact color cameras operate on 24V AC or
12V DC.
●
High-performance CCDs
Each camera incorporates a 1/4" CCD with a resolution
of 380,000 pixels (NTSC) (PAL 440,000 pixels)
resulting a high horizontal resolution that exceeds
480 lines (NTSC) (PAL 470 lines).
C-CV14-CS
C-CV24-2
Lens included
Lens included
●
2X varifocal lens
To easily allow on-site adjustment for the viewing
angle, each camera is fitted with a 2X manual
varifocal lens having an auto iris.
●
Wide-ranging view angles
Optimal camera angle of view extends from 53.2 to a
wide 105 degrees, enhancing coverage over a wide
range for more effective monitoring (C-CV14-2 and
C-CV24-2).
●
Versatile enough to handle less than perfect
lighting.
To cope with varying lighting conditions, backlight
compensation can be switched on or off as required.
●
Flicker-free for easier viewing
The cameras do not cause the image to deteriorate as
often caused by fluorescent lighting. Annoying image
flicker is eliminated for more effective monitoring.
●
Focus adjustment switch for easy focusing
To simplify focusing even without using the ND filter*,
an adjustment switch is provided for foolproof focusing.
*see rear page for more feature information.
C-CV14-2
C-CV44-3
