NETWORK CAMERA SYSTEM
About this installation guide
This guide describes the methods of connection, software installation, setting and operation,
which are necessary for assembling and operating basic network camera systems. For more
details, please refer to the instruction or setting manuals for each device used in the system.
TABLE OF CONTENTS
1. GENERAL DESCRIPTION ........................ 2
MANUAL COMPOSITION .................... 2
THE NETWORK CAMERA SYSTEM ........ 2
4.1. Before Making Connections ................ 3
4.2. Basic Connection Examples ................ 3
Connection Example ............................ 4
Connection Example ........................... 4
Connection Example ........................... 5
Connection Example ........................... 5
Connection Example............................ 5
SOFTWARE DECODER ............................ 6
SOFTWARE DECODER ............................ 7
Thank you for purchasing TOA's Network Camera System. Please carefully follow the instructions in this
manual to ensure long, trouble-free use of your equipment.
INSTALLATION GUIDE
8. OPERATION PROCEDURES .................... 8
11. CHANGING THE PC IP ADDRESS ......... 10
12. NOMENCLATURE AND FUNCTIONS .... 11
Device List by Scanning .................. 12
Device List Manually......................... 13
INSTALLED ON A PC ............................. 14
IMAGES VIA A RECEIVER ..................... 14
16. NORMAL RECORDING SETTINGS ........ 16
17.1. Video Recording Playback .............. 19
18. NETWORK VERIFICATION .................... 20
Advertisement
Table of Contents
Related Manuals for Toa N-CC2360
Summary of Contents for Toa N-CC2360
-
Page 1: Table Of Contents
SOFTWARE DECODER ... 6 7. UNINSTALLING THE SOFTWARE DECODER ... 7 Thank you for purchasing TOA's Network Camera System. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment. INSTALLATION GUIDE 8. OPERATION PROCEDURES ... 8 9. -
Page 2: General Description
Software decoder Installation Initial setting Operation confirmation Installation guide (This book you are reading now) N-CC2360 Instruction manual(Enclosed with the N-CC2360) Instruction manual (Enclosed with the N-CC2564) N-VT2010 Instruction manual (Enclosed with the N-VT2010) N-VR2010 Instruction manual (Enclosed with the N-VR2010) -
Page 3: System Construction
4.1. Before Making Connections 4.1.1. About the PoE* switching hub Because the N-VT2010 Network Video Transmitter, N-VR2010 Network Video Receiver, and N-CC2360 Network Color Camera are compatible with PoE Standards, power can be supplied to them using a single network cable. This eliminates the necessity for preparing a separate power supply in each camera installation location, and greatly improves installation freedom. -
Page 4: Making Connections
• Perform the electronic zoom setting to X2Cont, X4Cont, X8Cont, or X12Cont. Perform camera menu operation with the software decoder via a network. For details, refer to the N-SD2000 instruction manual and Combination dome camera setting manual. 5.2. Network Color Camera Connection Example Network Color Camera N-CC2360 Network Video Transmitter N-VT2010 Rear AUDIO ADJ. -
Page 5: Network Combination Dome Camera Connection Example
Note Because the power to the network combination dome camera is supplied from the existing AC line power source, the PoE switching hub need not be used. Network Combination Dome Camera N-CC2564 Note For more details about connection terminals, refer to the instruction manual for the network combination dome camera. -
Page 6: Installing The Software Decoder
6. INSTALLING THE SOFTWARE DECODER Install the N-SD2000 software decoder on a PC. 1. Insert the CD-ROM into the PC’s optical drive. When the PC recognizes the CD-ROM, the “Netcansee Setup Launcher” is automatically started. Note If the CD-ROM drive is not compatible with AutoRun, the Setup Launcher will not start when the CD-ROM is inserted. -
Page 7: Uninstalling The Software Decoder
3. The “InstallShield Wizard” window is displayed. Click on “Next” according to the on-screen instructions, then install the software decoder. (For the details about installation screen, refer to the software decoder instruction manual.) 4. Complete the installation. Restart the PC after the installation is completed. The “N-SD2000” shortcut is created on the PC’s desktop after restarted. -
Page 8: Operation Procedures
· Use of the Image Freeze function during display · Use of the Rectangular Display function found within the Motion Detection setting screen · Use of the White Frame display function used in the Zoom View function “TOA” “Netcansee” “N-SD2000.”... -
Page 9: Starting The Software Decoder
2. Select a network card. The network cards installed on the PC and their IP addresses are displayed in the Network card list. Select the card to use from this list. Notes • The software may not function correctly if an incorrect network card is selected. •... -
Page 10: Exiting The Software Decoder
10. EXITING THE SOFTWARE DECODER Click on the “X” button on the title bar to quit the software decoder. Note Turn off current on-screen images before quitting the software decoder. Failing to turn off images before quitting the software decoder may cause delays in renewing connections the next time the software decoder is started. -
Page 11: Nomenclature And Functions
12. NOMENCLATURE AND FUNCTIONS administration window (1) Tree View area Network cameras to be displayed in this area can be grouped together and registered to facilitate user understanding of the camera composition in each view. (2) Device Manager button Detects network devices connected to the LAN and displays the registration window. (3) Recording Search button Displays a window to be used to search for recordings made by the network video recorder. -
Page 12: Creating Device List
13. CREATING DEVICE LIST Registering network devices in the Device List allows live image playback, recording search and recorded image playback to be viewed on the software decoder as well as on a monitor connected to a receiver. Devices can be registered in the Device List using either of two methods, by scanning or manually. •... -
Page 13: Registering Devices In The Device List Manually
Use this registration method to register devices that are not currently connected to the network, or that are installed in areas outside of the local broadcast range in the Device List. 1. Click on “Device Manager” in the administration window. 2. -
Page 14: Displaying Live Images On The Software Decoder Installed On A Pc
3. Drag the device to be displayed from the Tree View to the desired view in the view window. The live image will be displayed once the connection is completed. Note: The N-VT2010, N-CC2360, and N-CC2564 can be registered in the Tree View. drag and drop... - Page 15 15. DISPLAYING LIVE IMAGES VIA A RECEIVER Display live images on the monitor connected to a receiver. 1. Register the receiver to be connected in the Device List. 2. Click on “Receiver” in the administration window. 3. Select the device to be displayed on the monitor from the Tree View, then drag it to the desired destination device in the receiver window.
-
Page 16: Normal Recording Settings
16. NORMAL RECORDING SETTINGS Select the N-DR2000 recorder registered in the Device Manager’s Device List and right-click on it. From the pull-down menu that appears after the selection, select “Browser connection (W).” The Web browser starts and the connection authentication screen is displayed. The authentication dialog is also displayed by directly entering the desired N-DR2000’s IP address in the Web browser’s “Address”... - Page 17 Click on the “menu” and then “Camera preset.” Enter the camera IP address to be recorded in the “IP address” column. If the network camera has been connected to a network, clicking on the “Get” button allows the set camera name to be automatically retrieved and entered.
- Page 18 Click on “Normal/Pre-alarm.” Perform settings for “Recording mode,” “Resolution,” “Quality,” “Frame rate,” and “Audio” for each camera, then click on the “Set” button. After the settings are completed, click on the Recording button to begin Normal recording. Clicking on “OK” the indication “Rec is stopped” to “Rec in progress.”...
-
Page 19: Video Recording Playback
17. VIDEO RECORDING PLAYBACK Search and retrieve video recordings made by the network video recorder and play them back on the software decoder. 17.1. Video Recording Playback 1. Register the network video recorder to be retrieved in the Device List. 2. -
Page 20: Network Verification
• The device is not correctly connected to the network. Check the device for correct wiring. • The device is not correctly set on the network. Check the IP address, subnet mask, and gateway. Enter "cmd" in the name, then click on "OK." URL: http://www.toa.jp/ 133-21-639-00...
