Oven Lampremoval; Upper Latch Switch And Monitor Switch (Australia Model) Removal; Lower Latch Switch Removal - Sharp R-8320E Service Manual

the outer case.
1. Disconnect the oven from the power supply and remove
the outer case.
2. Discharge the high voltage capacitor.
3. Remove the complete control panel assembly, referring
to the control panel assembly and component removal.
4. Disconnect the wire leads from the switches.
the switch in place.
1. Disconnect the oven from the power supply and remove
the outer case.
2. Discharge the high voltage capacitor.
3. Remove the complete control panel assembly, referring
to the control panel assembly and component removal.
4. Remove the single (1) screw and washer holding the
lower latch hook to the oven cavity front flange.
2. Discharge the high voltage capacitor.
3. Remove the oven lamp.
5. Remove the single (1) screw and washer holding the
upper latch hook to the oven cavity front flange.
6. Remove the upper latch hook from the flange by mov-
ing it downward.
7. To remove the individual switch from the upper latch
hook, push outward the two (2) retaining tabs holding
the switch in place.
5. Remove the lower latch hook from the flange by mov-
ing it downward.
6. Disconnect the wire leads from the switch.
7. Push outward the two (2) retaining tabs holding the
switch in place.
8. The switch is now free.
