PARTS LIST

KEY NO. DESCRIPTION
1 Main Base Frame
2 Front Stabilizer
3 Rear Stabilizer
4 Foot Platform
5 Long Pivot Support Bar
6 Short Pivot Support Bar
7 Weight Adjustment Bar
8 Seat Support
9 Arm Curl Stand
10 Leg Developer
11 Floating Double Pulley Bracket
12 Right Butterfly Arm
13 Left Butterfly Arm
14 Lower Main Frame
15 T-shaped Cable Connector
16 Vertical Frame
17 Lat Bar
18 Curl Bar
19 Backrest Pad
20 Arm Curl Pad
21 Seat
22 Curl Bar Tube
23 Bench Press Frame
24 Sliding Block
25 Bracket
26 Roller Wheel
27 2 3/8" Axle Cover
28 3 " Axle Cover
29 4 ½" Axle
30 1 3/4" Leg Developer Bumper
31 1 1/4" Vertical Frame Bumper
32 M10 x 2 5/8" Axle
33 M12 x 6 ½" Short Pivot Axle
34 M12 x 4" Butterfly Axle
35 M12 x 7 7/8" Long Pivot Axle
36 M12 Aircraft Nut
37 M10 x 2 ¼" Leg Developer Axle
38 125" Upper Cable
39 108 " Lower Cable
40 Chain
41 Ankle Strap
42 AB Strap
43 Single Handle
44 2 3/4" Pulley
45 3 3/4" Pulley
Q'ty
46
1 47
1 48
1 49
50
1
51
2
2 52
1 53
1 54
1 55
1 56
57
2
1 58
1 59
1 60
1 61
1 62
63
1
64
1
1 65
1 66
1 67
1 68
1 69
70
1
2 71
2 72
2 73
4 74
1 75
76
1
77
4
78
1
79
3
2 80
81
2
14
82
1
83
1
84
1
85
2
86
1
87
1
88
1
11
1
12
Pulley Bushing
Lock Knob
Foam Roll Tube
Clip
1" Bushing
Foam Roll
Foam Roll End Cap
2" End Cap
2" x 1 " Square End Cap
2 1/4" x 1 1/8" End Cap
Stabilizer End Cap
Grip
Lat Bar Grip
M10 x 2 ½" Allen Bolt
M10 x 1 ¾" Allen Bolt
Cone Shaped Stopper
Rubber Ball Bumper
Cable Washer
Cable Connector
Leg Developer Holder Sleeve
2 ¼" Sleeve
Cone-shaped Cap
1 3/8" Bushing
M10 x 2 3/4" Carriage Bolt
M10 x 2 ½" Carriage Bolt
M10 x 5/8" Allen Bolt
M10 x 5 ½" Allen Bolt
M8 x 2 ½" Allen Bolt
M8 x 1 ¾" Allen Bolt
M8 x 5/8" Allen Bolt
M6 x 5/8" Screw
M10 Aircraft Nut
Square Sleeve
1" Washer
1 ½" Washer
Large Washer
7/8" Washer
3/4" Washer
Allen Wrench #6
Allen Wrench #5
Spring Clip
Weight Holder
Round End Cap
12
3
2
2
32
4
4
7
16
2
4
6
2
6
5
1
1
1
1
1
2
14
2
8
1
6
1
2
2
2
6
21
2
10
4
6
21
6
2
1
2
1
2
