NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Pack
Assembly Instruction
Parts List
Resistance Chart
Warranty
Ordering Parts
Model
MWM-982
Retain This
Manual for
Reference
100621
OWNER'S
MANUAL
MARCY
HOME GYM
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
®
MWM 982
®
IMPEX
INC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MWM 982 and is the answer not in the manual?

Questions and answers

Related Manuals for Impex MWM 982

Summary of Contents for Impex MWM 982

  • Page 1 NOTE: Please read all instructions carefully before using this product Table of Contents ® Safety Notice MARCY MWM 982 Hardware Pack HOME GYM Assembly Instruction Parts List Resistance Chart Warranty Ordering Parts Model MWM-982 Retain This Manual for Reference 100621 ®...

  • Page 2: Table Of Contents

    ORDERING PARTS...................………….. 25 BEFORE YOU BEGIN ® Thank you for selecting the MARCY MWM-982 HOME GYM by IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notices

    BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES RESPONSIBILITY PERSONAL INJURY PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.

  • Page 4: Warning Label Placement

    WARNING LABEL PLACEMENT The warning labels shown here have been placed on the Rear Stabilizer and Upper Frame. If the labels are missing or illegible, please call customer service at 1-800-888-8899 for replacements. Apply the labels in the location shown.

  • Page 5: Hardware Identifier

    HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 6 HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTION Tools Required for Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended that this machine to be assembled by two or more people to avoid possible injury. STEP 1 (See Diagram 1) A.) Do not tighten all Nuts and Bolts starting from this procedure until instructed to do so.
  • Page 8 DIAGRAM 1...
  • Page 9 STEP 2 (See Diagram 2) A.) Do not tighten all Nuts and Bolts until instructed to do so. B.) Align the holes on the Upper Frame (#1) with the top of the Guide Rods (#11). Place the Upper Frame onto the Vertical Frame (#4). C.) Secure the Upper Frame to the Guide Rods with two M10 x 1”...
  • Page 10 DIAGRAM 2...
  • Page 11 STEP 3 (See Diagram 3) A.) Attach the Front Press Base (#8) to the Upper Frame (#1). Secure it with one 8 ½” Front Press Axle (#19), two Ø 1” x Ø 5/8” Washers (#75), and two M10 Aircraft Nuts (#70). Do not over tighten the Nuts.
  • Page 12 DIAGRAM 3...
  • Page 13 STEP 4 (See Diagram 4) A.) Insert the Front Press Handle (#12) into the hole on Right Butterfly (#10) and Left Butterfly (#9). Secure each Handle with one M8 x ¾” Allen Bolt (#61) and one Ø 5/8” Curved Washer (#76). B.) Insert 15 ¾”...
  • Page 14 STEP 5 (See Diagram 5) A.) Attach one Swivel Pulley Bracket (#17) to the open bracket on the back of Vertical Frame (#4). Secure it with one M10 x 2 ½” Allen Bolt (#66), two Ø ¾” Washers (#73), and one M10 Aircraft Nut (#70). Do not over tighten the Nut and Bolt. Make sure the Swivel Pulley Bracket can swivel freely.
  • Page 15 CABLE LOOP DIAGRAM...
  • Page 16 STEP 6 (See Diagram 6 & Cable Loop Diagram) A.) Attach the 126” Upper Cable (#32) to the front open bracket under the Upper Frame (#1). B.) Attach a Pulley (#35) to the bracket. Secure it with one M10 x 1 ¾” Allen Bolt (#62), two Ø...
  • Page 17 DIAGRAM 6...
  • Page 18 STEP 7 (See Diagram 7& Cable Loop Diagram) A.) Hook one end of the 98” Butterfly Cable (#34) to Right Butterfly (#10). B.) Draw the Cable towards the right open Swivel Pulley Bracket (#17). C.) Attach a Pulley (#35) to the bracket. Secure it with one M10 x 1 ¾” Allen Bolt (#62), two  ¾” Washers (#73), and one M10 Aircraft Nut (#70).
  • Page 19 STEP 8 (See Diagram 8 & Cable Loop Diagram) A.) Attach the 164” Lower Cable (#33) to the open bracket on the Base Frame (#3). B.) Attach a Pulley (#35) to the bracket. Secure it with one M10 x 1 ¾” Allen Bolt (#62), two ...
  • Page 20 DIAGRAM 8...
  • Page 21 STEP 9 (See Diagram 9) A.) Attach Lat Bar (#14) to the Upper Cable (#32) with two Hooks (#53) and one 15-link Chain (#54) when doing Lat Pull exercises. B.) Attach Shiver Bar (#15) to the Lower Cable (#33) use the two Hooks (#53) and the 15-link Chain (#54) from Lat Bar when doing Arm Curl exercises C.) Replace Shiver Bar with the Ankle Strap (#52) or Single Handle (#78) to the Lower Cable for various exercises.
  • Page 22 STEP 10 (See Diagram 10) A.) Attach two Weight Stack Cover Brackets (#74) to top and bottom holes on a Weight Stack Cover (#79). B.) Secure the Weight Stack Cover and Weight Stack Cover Brackets to Upper Frame (#1) and Base Frame (#3) with four M8 x 5/8”...

  • Page 23: Combination Lock Set Up Instruction

    Combination Lock Set Up Instruction The Lock is set at the manufacturer to the open at 0-0-0 (all zeros are positioned in the middle). It is recommended to change the combination to ensure safety. Please follow the below steps to change the combination: 1.

  • Page 24: Parts List

    PARTS LIST KEY NO. DESCRIPTION Q’ty Upper Frame Selector Stem Rear Stabilizer Ankle Strap Base Frame Hook Vertical Frame 15-link Chain Seat Support 2” x 2” End Cap Vertical Seat Support Ø 1” x 3/8” Bushing Leg Developer Ø 1” x Ø 5/8” Pulley Bushing Front Press Base M10 x 2 3/8”...

  • Page 25: Resistance Chart

    MWM982 WEIGHT RESISTANCE CHART Weight Plate Front Butterfly Developer Press Pull Pulley Note: Each plate weights 10 lbs. Numbers are approximate. Actual weights may vary. Values for Butterfly are for each arm.

  • Page 26: Warranty

    IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
