Follett HCC1000A Operation And Service Manual

Follett HCC1000A Operation And Service Manual

Hcc1000a, hcc1000w icemakers
Hide thumbs Also See for HCC1000A:
Table of Contents

Advertisement

Quick Links

Download this manual
Order parts online
www.follettice.com
Following installation, please forward this manual
HCC1000A, HCC1000W Icemakers
to the appropriate operations person.
801 Church Lane • Easton, PA 18040, USA
Toll free (800) 523-9361 • (610) 252-7301
Fax (610) 250-0696 • www.follettice.com
Operation and Service Manual
00129932R06

Advertisement

Table of Contents
loading

Related Manuals for Follett HCC1000A

Summary of Contents for Follett HCC1000A

  • Page 1 HCC1000A, HCC1000W Icemakers Order parts online Operation and Service Manual www.follettice.com Following installation, please forward this manual to the appropriate operations person. 801 Church Lane • Easton, PA 18040, USA Toll free (800) 523-9361 • (610) 252-7301 Fax (610) 250-0696 • www.follettice.com...
  • Page 2 Follett Corporation Equipment Return Policy Follett equipment may be returned for credit under the following conditions: The equipment is new and unused. A return authorization number has been issued by customer service within 30 days after shipment. Follett receives the equipment at the factory in Easton, PA within 30 days after issuance of the return authorization number. The equipment must be returned in Follett packaging.

  • Page 3: Table Of Contents

    Table of contents Welcome to Follett Corporation Specifications Operation Cleaning Weekly exterior care Monthly condenser cleaning Semi-annual evaporator cleaning Service Icemaker operation Water system Electrical system Normal control board operation Test points Time delay and self-flushing jumpers Error faults Hard error Soft errors Relay output indication Compressor/refrigerant solenoid output...

  • Page 4: Welcome To Follett Corporation

    Welcome to Follett Follett equipment enjoys a well-deserved reputation for excellent performance, long-term reliability and outstanding after-the-sale support. To ensure that this equipment delivers the same degree of service, we ask that you review the installation manual (provided as a separate document) before beginning to install the unit. Our instructions are designed to help you achieve a trouble-free installation.

  • Page 5: Specifications

    Specifications Electrical Each icemaker requires its own separate circuit with electrical disconnect within 10 ft (6m). Equipment ground required. Standard electrical – 208-230/60/1 Maximum icemaker fuse – 15 amps each Amperage – 11 amps 6 ft (2m) NEMA 6-15 cord and plug provided on icemaker Plumbing 3/8"...
  • Page 6 1" (26mm) minimum clearance on sides. The intake and exhaust air grilles must provide at least 150 sq in (968 sq cm) of open area. Air-cooled model HCC1000A icemakers – 18" (458mm) minimum clearance between discharge and air intake-grilles. Front View...

  • Page 7: Operation

    Operation Cleaning and preventive maintenance (all models) Note: Do not use bleach to sanitize or clean the icemaker. Preventive maintenance Periodic cleaning of Follett’s icemaker system is required to ensure peak performance and delivery of clean, sanitary ice. The recommended cleaning procedures that follow should be performed at least as frequently as recommended, and more often if environmental conditions dictate.
  • Page 8 Fig. 2 2. Mix 1 gallon (3.8L) 120˚F (49˚C) water and 7 ounces (198g) (one 7 ounce packet of Follett SafeCLEAN ice machine cleaner, part#-00132001). Locate cleaning cup. Fill until HI WATER light comes on (Fig. 2). HI WATER Note: Do not use bleach to sanitize or clean the icemaker.
  • Page 9 Fig. 5 5. Mix 1 gallon 120˚F (49˚C) water and 1.6 ounces (48ml) NU-CALGON IMS-II SANITIZER. Fill until HI WATER light comes on (Fig. 5). Note: Do not use bleach to sanitize or clean the HI WATER icemaker. Fig. 6 6.
  • Page 10 Fig. 8 8. Disconnect coupling as shown (Fig. 8). Fig. 9 9. Using disposable food service grade gloves, insert dry Sani-Sponge ™ (kit part# 00132068). Next,-insert Sani-Sponge soaked in Nu-Calgon IMS-II sanitizer solution. Push both Sani-Sponges down ice transport tube with supplied pusher tube (Fig.
  • Page 11 Fig. 11 11. Reconnect coupling. Press power switch ON. Ice pushes Sani-Sponges through tube (Fig. 11). 12. Place a sanitary (2 gallon or larger) container in Fig. 12 bin or dispenser to collect Sani-Sponges and ice for 10 minutes. Collect 5.5 lbs of ice from unit. Discard ice and Sani-Sponges (Fig.

  • Page 12: Service

    Service Icemaker operation (all models) Follett’s icemaker consists of five distinct functional systems covered in detail as follows: • Water system • Electrical control system • Mechanical assembly • Refrigeration system • Bin full The Horizon icemaker overview The Follett Horizon icemaker uses a horizontal, cylindrical evaporator to freeze water on its inner surface. The refrigeration cycle is continuous;...

  • Page 13: Water System

    Water system The water level in the evaporator is controlled by a feed solenoid and level detecting sensors. Referencing the diagram below, water sensing rods extend down into the reservoir at the end of the evaporator assembly. The system works via electrical conductivity as follows: One of the longest probes is a common.

  • Page 14: Electrical System

    Electrical system Normal control board operation The PC board indicator lights provide all the information necessary to determine the machine's status. Green indicator lights generally represent “go” or normal operation; Yellow indicators represent normal off conditions; Red indicators generally represent alarm conditions, some of which will lock the machine off. A green light labeled POWER indicates power to the machine.

  • Page 15: Test Points

    Test points: The Horizon PC board incorporates on-board test points that can be used to determine various electrical outputs. The test point holes allow a standard probe to be inserted for quick voltage measurement. For 208-230 systems, use TP-4 (L2) as the common for testing outputs for solenoids, motors, etc. Time delay and self-flushing jumpers: The duration of the Time Delay period, the time between normal shut down and restart, is jumper selectable.

  • Page 16: Wiring Diagram

    Wiring diagram SNUBBER POWER (G) LOW BIN (G) AUGER ON (G) REFRIG ON (G) TIME DELAY (Y) CLEANING (Y) PURGE (Y) SERVICE (R) HI AMPS (R) CONTROL PC BOARD HI PRESS (R) LO PRESS (R) DRAIN CLOG (R) HI WATER (R) LO WATER (R) CPU (G) (DEFAULT)

  • Page 17: Compressor Data

    Compressor data Compressor current draw Air-cooled Ambient air temp. 60˚F/16˚C 70˚F/21˚C 80˚F/27˚C 90˚F/32˚C 100˚F/38˚C 6.4A 6.4A 6.8A 7.4A 7.6A Water-cooled Condenser water temp 50˚F/10˚C 60˚F/16˚C 70˚F/21˚C 80˚F/27˚C 90˚F/32˚C 6.5A 6.6A 6.8A 7.3A 7.5A Locked rotor amps Gearmotor data Brother Gearmotor current 2.8A (nominal) Locked rotor amps 15 amps...

  • Page 18: Mechanical System

    Mechanical system Fig. 13 Evaporator disassembly 1. Press PURGE button to purge evaporator, and then turn power OFF. 2. Unscrew and remove stream divider as shown. Fig. 14 3. Unplug and remove gearmotor as shown. 4. Remove all traces of anti-seize compound or petrol-gel from the auger shaft.
  • Page 19 Fig. 16 8. Loosen nut on V-band clamp and remove. 9. Remove V-band clamp from front of evaporator. 10. Remove main housing as shown. Fig. 17 11. Remove and discard mating ring and seal. 12. Carefully remove auger.

  • Page 20: Evaporator Reassembly

    Fig. 18 Evaporator reassembly 1. Remove and inspect O ring seal. Discard if damaged in any way. 2. Clean O ring groove. Lubricate O ring with petrol-gel and reinstall. Fig. 19 3. Press new mating ring into main housing as shown. 4.
  • Page 21 Fig. 21 6. Orient auger shaft with keyway in the Note: Shuttle housing upward position. removed for clarity 7. Force main housing into position against evaporator and place 1/4" (7mm) diameter Phillips screwdriver into hole in the auger shaft. 8. Replace V-band clamp as shown. 9.
  • Page 22 Fig. 24 17. Insert a bolt into the auger shaft and finger tighten. 18. Using a wrench, rotate the shaft clockwise to align the keyways in the gear housing and the shaft so as to accept the key. 19. Insert the key into the keyway. Fig.

  • Page 23: Refrigeration System

    Refrigeration system Refrigerant pressure data Air-cooled condensers (air) 60˚F/16˚C 70˚F/21˚C 80˚F/27˚C 90˚F/32˚C 100˚F/38˚C Pressure (psig) discharge/suction 217/29 250/32 284/35 325/39 366/43 Water-cooled condensers (water) 60˚F/16˚C 70˚F/21˚C 80˚F/27˚C 90˚F/32˚C 100˚F/38˚C Pressure (psig) discharge/suction 275/34 275/34 275/34 280/34 302/36 Note: The water control valve is factory set to maintain 275 ± 15 psi discharge pressure @ 70˚F water. Refrigeration system diagram high side high side...

  • Page 24: Refrigerant Charge Size

    Recharging icemaker to other than factory specifications will void the warranty. R404A icemaker charge specifications Model Charge Refrigerant type HCC1000A (air-cooled) 24oz (652g) R404A HCC1000W (water-cooled) 15oz (426g) R404A Refrigerant replacement requirements 1.

  • Page 25: "Bin Full" Detection System

    “Bin full” detection system The Follett Horizon icemaker incorporates a unique “bin full” detection system that consists of the shuttle and actuator. The shuttle incorporates a flag and sensor. Referencing the figure below, the normal running position of the flag is down, out of the sensor. When the bin fills to the top and ice can no longer move through the tube, the machine will force the shuttle flag up into the sensor, shutting the machine off.

  • Page 26: Troubleshooting

    Troubleshooting Please see “Service” section for a description of each function. Ice machine disposition Possible causes Corrective actions Legend: ON or OFF FLASHING 1. Ice machine is in running 1. Defective compressor. 1. Replace compressor. condition but not making ice. 2.
  • Page 27 Ice machine disposition Possible causes Corrective actions Legend: ON or OFF FLASHING 7. Ice machine is not making ice. 1. Drain hose kinked or plugged 1. Remove kink or blockage from Drain clog. causing water to back up. drain hose. 2.

  • Page 28: Replacement Parts

    Replacement parts Order parts online www.follettice.com Evaporator assembly...
  • Page 29 Order parts online www.follettice.com Reference # Description Part # Tube, ice transport, molded 00130666 Shuttle assembly (includes 00115600 & 0013066) 00130815 Switch, optical 00130849 Compression nozzle 00115774 Elbow, water 00134502 Gasket, shuttle 00115600 Stream divider 00142513 Auger bolt 00116988 Washer 00161513 Retainer, auger bolt 00161366...
  • Page 30 Air-cooled assembly Order parts online www.follettice.com...
  • Page 31 Order parts online www.follettice.com Reference # Description Part # Condenser (includes 00130922) 00130914 Shroud, condenser 00130922 Fan motor assembly 00130930 Electrical box support 00156035 Cut-out, high pressure safety 00117077 Insulation, bulb, TXV 00106534 Drier 502724 Valve, expansion, thermal (includes 502830 and 00106534) 00130997 Insulation, TXV 502830...
  • Page 32 Water-cooled assembly Order parts online www.follettice.com...
  • Page 33 Order parts online www.follettice.com Reference # Description Part # Electrical box support 00156035 Elbow, water 00129486 Valve, water regulating 00131052 Union, water 202148 Cut-out, high pressure safety 00117077 Insulation, bulb, TXV 00106534 Drier 502724 Valve, expansion, thermal (includes 502830 and 00106534) 00130997 Insulation, TXV 502830...
  • Page 34 Electrical box Order parts online www.follettice.com...
  • Page 35 Order parts online www.follettice.com Reference # Description Part # Cover, electrical box, air/water-cooled 00130872 Board, control circuit, 240V (includes 00130906) 00132902 Stand off’s (set of 6) 00130906 Capacitor, compressor run 00133512 Clamp, run capacitor 00133603 Relay, compressor starting (includes wire harness) 00161810 Contactor 00117010...
  • Page 36 Integration kit – top-mount and Satellite-fill Order parts online www.follettice.com...
  • Page 37 Order parts online www.follettice.com Reference # Description Part # Shuttle actuator 00131029 O ring, ice tube 00123836 Retainer, ice tube 00129270 Nut, ice tube coupling 00122804 Tube, ice-fill, coupling to shuttle actuator 00119222 Insulation, coupling to shuttle actuator 00132605 Tube, ice-fill, 1400 top mount (includes 00128173) 00131011 Insulation, fill tube, 1400 top mount 00128173...
  • Page 38 Skins assembly Order parts online www.follettice.com Stock Module Identification Plate 208264 Module No. Product Service No.
  • Page 39 Order parts online www.follettice.com Reference # Description Part # Grille, intake 00122846 Front cover, air- & water-cooled (includes 00122846) 00130625 Tubing, water, 1/4" OD 502079 Tubing, drain 00144923 Fitting, drain 00109728 Fitting, water inlet 502924 Elbow, water inlet 502925 Nut, ice tube coupling 00122804 Retainer, ice tube 00129270...
  • Page 40 Chewblet is a registered trademark of Follett Corporation, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (800) 523-9361 • (610) 252-7301 00129932R06 02/07 Fax (610) 250-0696 • www.follettice.com...
