www.follettice.com
Following installation, please forward this manual
HCC/HMC1000A, HCC/HMC1000W
to the appropriate operations person.
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
Operation and Service Manual
Serial Number C20001 to C33984
Ice Machines
00171579R15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C20001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Follett C20001

Summary of Contents for Follett C20001

  • Page 1 Ice Machines Order parts online Operation and Service Manual www.follettice.com Serial Number C20001 to C33984 Following installation, please forward this manual to the appropriate operations person. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 00171579R15 www.follettice.com...

  • Page 3: Table Of Contents

    Table of contents Welcome to Follett Corporation Specifications Operation Cleaning Weekly exterior care Monthly condenser cleaning Semi-annual evaporator cleaning Service Ice machine operation Water system Electrical system Normal control board operation Test points Error faults Hard error Soft errors Relay output indication...

  • Page 4: Welcome To Follett Corporation

    Before you begin After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If damage is found, notify the shipper immediately and contact Follett Corporation so that we can help in the filing of a claim, if necessary.

  • Page 5: Specifications

    To prevent back flow, do not connect drains. Separate drains for ice machine and condenser. Water shut-off recommended within 10 feet (3m). Follett recommends installation of Follett water filter system (part# 00130286) in ice machine inlet water line. Ambient Air temperature 100 F/38 C max.

  • Page 6: Operation

    Do not use bleach to sanitize or clean the ice machine. Preventive maintenance Periodic cleaning of Follett’s ice machine system is required to ensure peak performance and delivery of clean, sanitary ice. The recommended cleaning procedures that follow should be performed at least as frequently as recommended, and more often if environmental conditions dictate.

  • Page 7: Semi-Annual Evaporator Cleaning

    • Wear rubber gloves and safety goggles (and/or face shield) when handling ice machine cleaner or sanitizer CAUTION • Use only Follett approved SafeCLEAN™ Cleaner (part #00132001) and NU-CALGON IMS-II or IMS-III SANITIZER. • Do not mix Cleaner and Sanitizer solutions together.
  • Page 8 Fig. 2 2. Mix 1 gallon (3.8L) 120 F (49 C) water and 7 ounces (198g) (one 7 ounce packet of Follett SafeCLEAN ice machine cleaner, part#-00132001). Locate cleaning cup. Fill until HI WATER light comes on (Fig. 2). HI WATER Note: Do not use bleach to sanitize or clean the ice machine.
  • Page 9 Fig. 5 5. Mix 1 gallon 120 F (49 C) water and 1.6 ounces (48ml) NU-CALGON IMS-II or IMS-III SANITIZER. Fill until HI WATER light comes on (Fig. 5). Note: Do not use bleach to sanitize or clean the ice machine. HI WATER Fig.
  • Page 10 Fig. 8 8. Disconnect coupling as shown (Fig. 8). Fig. 9 9. Using disposable food service grade gloves, insert dry Sani-Sponge (kit part# 00132068). Next, ™ -insert Sani-Sponge soaked in Nu-Calgon IMS-II or IMS-III sanitizer solution. Push both Sani-Sponges down ice transport tube with supplied pusher tube (Fig. 9).
  • Page 11 Fig. 11 11. Reconnect coupling. Press power switch ON. Ice pushes Sani-Sponges through tube (Fig. 11). Fig. 12 12. Place a sanitary (2 gallon or larger) container in bin or dispenser to collect Sani-Sponges and ice for 10 minutes. Collect 5.5 lbs (3kg) of ice from unit. Discard ice and Sani-Sponges (Fig.

  • Page 12: Service

    The Horizon ice machine overview The Follett Horizon ice machine uses a horizontal, cylindrical evaporator to freeze water on its inner surface. The refrigeration cycle is continuous; there is no batch cycle. The evaporator is flooded with water and the level is controlled by sensors in a reservoir.

  • Page 13: Water System

    Water system The water level in the evaporator is controlled by a feed solenoid and level detecting sensors. Referencing the diagram below, water sensing rods extend down into the reservoir at the end of the evaporator assembly. The system works via electrical conductivity as follows: One of the longest probes is a common.

  • Page 14: Electrical System

    Electrical system Normal control board operation The PC board indicator lights provide all the information necessary to determine the machine's status. Green indicator lights generally represent “go” or normal operation; Yellow indicators represent normal off conditions; Red indicators generally represent alarm conditions, some of which will lock the machine off. A green light labeled POWER indicates power to the machine.

  • Page 15: Test Points

    A soft error can either be automatically reset should the condition rectify, or if power is cycled. Should an error occur, consult the troubleshooting guide in this manual or a Follett service technician. Note: there are two types of LO WATER and HI AMPS errors as listed below.

  • Page 16: Wiring Diagram

    Wiring diagram POWER (G) LOW BIN (G) AUGER ON (G) REFRIG ON (G) TIME DELAY (Y) CLEANING (Y) PURGE (Y) SERVICE (R) HI AMPS (R) HI PRESS (R) CONTROL BOARD LO PRESS (R) DRAIN CLOG (R) HI WATER (R) LO WATER (R) CPU (G)

  • Page 17: Compressor Data

    Compressor data Compressor current draw at 230 VAC Air-cooled Ambient air temp. 60 F/16 C 70 F/21 C 80 F/27 C 90 F/32 C 100 F/38 C Water-cooled Condenser water temp 50 F/10 C 60 F/16 C 70 F/21 C 80 F/27 C 90 F/32 C Locked rotor amps...

  • Page 18: Mechanical System

    Mechanical system Fig. 13 Evaporator disassembly Press PURGE button to purge evaporator, and then turn power OFF. 2. Unscrew and remove stream divider as shown. Fig. 14 3. Unplug and remove gearmotor as shown. 4. Remove all traces of petrol-gel from the auger shaft. Fig.
  • Page 19 Fig. 16 8. Loosen nut on V-band clamp and remove. 9. Remove V-band clamp from front of evaporator. 10. Remove main housing as shown. Fig. 17 11. Remove and discard mating ring and seal. 12. Carefully remove auger.

  • Page 20: Evaporator Reassembly

    Fig. 18 Evaporator reassembly Remove and inspect O ring seal. Discard if damaged in any way. 2. Clean O ring groove. Lubricate O ring with petrol-gel and reinstall. Fig. 19 3. Press new mating ring into main housing as shown. 4.
  • Page 21 Fig. 21 6. Orient auger shaft with keyway in the Note: Shuttle housing upward position. removed for clarity Force main housing into position against evaporator and place 1/4" (7mm) diameter Phillips screwdriver into hole in the auger shaft. 8. Replace V-band clamp as shown. 9.
  • Page 22 Fig. 24 17. Insert a bolt into the auger shaft and finger tighten. 18. Using a wrench, rotate the shaft clockwise to align the keyways in the gear housing and the shaft so as to accept the key. 19. Insert the key into the keyway. Fig.

  • Page 23: Refrigeration System

    Refrigeration system Refrigerant pressure data Air-cooled condensers (air) 60 F/16 C 70 F/21 C 80 F/27 C 90 F/32 C 100 F/38 C Pressure (psig) discharge/ 218/31 241/33 277/35 313/38 349/41 suction Water-cooled condensers 60 F/16 C 70 F/21 C 80 F/27 C 90 F/32 C 100 F/38 C...

  • Page 24: Refrigerant Charge Size

    R404A Refrigerant replacement requirements 1. Non-contaminated refrigerant removed from any Follett refrigeration system can be recycled and returned to the same system after completing repairs. Recycled refrigerant must be stored in a clean, approved storage container. If additional refrigerant is required, virgin or reclaimed refrigerant that meets ARI standard 700-88 must be used.

  • Page 25: "Bin Full" Detection System

    “Bin full” detection system The Follett Horizon ice machine incorporates a unique “bin full” detection system that consists of the shuttle and actuator. The shuttle incorporates a flag and sensor. Referencing the figure below, the normal running position of the flag is down, out of the sensor. When the bin fills to the top and ice can no longer move through the tube, the machine will force the shuttle flag up into the sensor, shutting the machine off.

  • Page 26: Troubleshooting

    Troubleshooting Please see “Service” section for a description of each function. Ice machine disposition Possible causes Corrective action Legend: ON or OFF FLASHING Ice machine is in running 1. Defective compressor. 1. Replace compressor. 2. Defective start relay. 2. Replace start relay. condition but not making ice.
  • Page 27 Ice machine disposition Possible causes Corrective action Legend: ON or OFF FLASHING 6. Ice machine is not making ice. 1. High ambient temperatures 1. Air condition area to below HI PRESSURE. >100 F (38 C). 100 F (38 C). 2. Poor ventilation or air 2.

  • Page 28: Replacement Parts

    Replacement parts Order parts online www.follettice.com Evaporator assembly 18 17...
  • Page 29 Order parts online www.follettice.com Reference # Description Part # Tube, ice transport, molded 00175299 Shuttle assembly (includes gasket and nozzle) 00130815 Switch, optical 00130849 Compression nozzle 00115774 Elbow, water 00134502 Gasket, shuttle 00115600 Stream divider 00142513 Auger bolt 00116988 Washer 00161513 Retainer, auger bolt 00161356...
  • Page 30 Air-cooled assembly Order parts online www.follettice.com...
  • Page 31 Order parts online www.follettice.com Reference # Description Part # Condenser (includes 00130922) 00130914 Shroud, condenser 00130922 Fan motor assembly 00130930 Electrical box support 00153635 Cut-out, high pressure safety 00117077 Insulation, bulb, TXV 00106534 Drier 502724 Valve, expansion, thermal (includes 502830 and 00106534) 00130997 Insulation, TXV 502830...
  • Page 32 Water-cooled assembly Order parts online www.follettice.com...
  • Page 33 Order parts online www.follettice.com Reference # Description Part # Electrical box support 00153635 Elbow, water 00129486 Valve, water regulating 00131052 Union, water 202148 Cut-out, high pressure safety 00117077 Insulation, bulb, TXV 00106534 Drier 502724 Valve, expansion, thermal (includes 502830 and 00106534) 00130997 Insulation, TXV 502830...
  • Page 34 Electrical box Order parts online www.follettice.com...
  • Page 35 Order parts online www.follettice.com Reference # Description Part # Cover, electrical box, air/water-cooled 00130872 Board, control circuit, 240V (includes 00130906) 00132902 Stand off’s (set of 6) 00130906 Capacitor, compressor run 00121814 Clamp, run capacitor 00133603 Relay, compressor starting (includes wire harness) 00157123 Contactor 00917195...
  • Page 36 Integration kit – top-mount and RIDE remote ice delivery equipment Order parts online ® www.follettice.com Top mount configuration RIDE model configuration...
  • Page 37 Diverter plate (single agitator Cornelius dispensers and left-hand 307277 dispense chute on dual-agitator Cornelius dispensers) Not shown Diverter plate (right-hand dispense chute on dual-agitator dispensers) 00996207 Not shown Follett SafeCLEAN ice machine cleaner (case of 24 x 7oz packets) 00132001 Not shown Sani-Sponge kit 00132068...
  • Page 38 Skins assembly Order parts online www.follettice.com ni a sy lva st on SI NG TI O RI AL O RA M AL SI DE R TH E US M PR M OT H SI HI G N PR SI G .
  • Page 39 Order parts online www.follettice.com Reference # Description Part # Grille, intake 00122846 Front cover, air- & water-cooled (includes 00122846) 00130625 Tubing, water, 1/4" OD 502719 Tubing, drain 00144923 Fitting, drain 00109728 Fitting, water inlet 502924 Elbow, water inlet 502925 Coupling (includes 00144675) 00171207 O ring 00144675...
  • Page 40 Horizon, Harmony, Ice Manager, SafeCLEAN, Sani-Sponge and Vision are trademarks of Follett Corporation. Chewblet, RIDE and Follett are registered trademarks of Follett Corporation, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 00171579R15 ©...
