  • Page 1 HCD/HMD/HCF/HMF1000R, HCD/HMD1000N Ice Machines Order parts online Operation and Service Manual www.follettice.com After Serial Number C20000 Following installation, please forward this manual to the appropriate operations person. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01034719R03 www.follettice.com...
  • Page 2 Horizon 1000R/N Ice Machines...

  • Page 3: Table Of Contents

    Table of contents Welcome to Follett Corporation ..........................4 Specifi cations ................................5 Operation ..................................7 Cleaning, weekly exterior care ..........................7 Cleaning, semi-annual evaporator cleaning ......................7 Service ..................................12 Ice machine operation ............................12 Water system ............................... 13 Electrical system ..............................

  • Page 4: Welcome To Follett Corporation

    Welcome to Follett Follett equipment enjoys a well-deserved reputation for excellent performance, long-term reliability and outstanding after-the-sale support. To ensure that this equipment delivers the same degree of service, we ask that you review the installation manual (provided as a separate document) before beginning to install the unit. Our instructions are designed to help you achieve a trouble-free installation.

  • Page 5: Specifi Cations

    Specifi cations Electrical Separate circuit and equipment ground required. Evaporator unit Standard electrical – 115/60/1 Maximum fuse – 15A Amperage – 6A Condensing unit Single-Phase 3-Phase Electrical 208-230 V, 60 Hz 208-230 V, 60 Hz Maximum Circuit HVACR breaker size Minimum Circuit Ampacity 10.7A 9.9A...
  • Page 6 Dimensions and clearances Entire front of ice machine must be clear of obstructions/connections to allow removal. 1" (26 mm) clearance above ice machine for service. 1" (26 mm) minimum clearance on sides. Front View Side View Back View Ice transport hose connection 21.28"...

  • Page 7: Operation

    Operation Cleaning and preventive maintenance (all models) Note: Do not use bleach to sanitize or clean the ice machine. Preventive maintenance Periodic cleaning of Follett’s ice machine system is required to ensure peak performance and delivery of clean, sanitary ice. The recommended cleaning procedures that follow should be performed at least as frequently as recommended, and more often if environmental conditions dictate.
  • Page 8 Fig. 2 2. Mix 1 gallon (3.8 L) 120 F (49 C) water and 7 oz (198 g) (one 7 oz packet of Follett SafeCLEAN ice machine cleaner, P/N 00132001). Locate cleaning cup. Fill until HI WATER light comes on (Fig. 2). HI WATER Note: Do not use bleach to sanitize or clean the ice machine.
  • Page 9 Fig. 5 5. Mix 1 gallon 120 F (49 C) water and 1.6 oz (48 ml) NU-CALGON IMS-II SANITIZER. Fill until HI WATER light comes on (Fig. 5). Note: Do not use bleach to sanitize or clean the ice machine. HI WATER Fig.
  • Page 10 Fig. 8 8. Disconnect coupling as shown (Fig. 8). Fig. 9 9. Using disposable food service grade gloves, insert dry Sani-Sponge™ (kit P/N 00132068). Next, insert Sani- Sponge soaked in Nu-Calgon IMS-II sanitizer solution. Push both Sani-Sponges down ice transport tube with supplied pusher tube (Fig.
  • Page 11 Fig. 11 11. Reconnect coupling. Press power switch ON. Ice pushes Sani-Sponges through tube (Fig. 11). Fig. 12 12. Place a sanitary (2 gallon or larger) container in bin or dispenser to collect Sani-Sponges and ice for 10 minutes. Collect 5.5 lb (3 kg) of ice from unit. Discard ice and Sani-Sponges (Fig.

  • Page 12: Service

    Service Ice machine operation (all models) Follett’s ice machine consists of fi ve distinct functional systems covered in detail as follows: • Water system • Electrical control system • Mechanical assembly • Refrigeration system • Bin full The Horizon ice machine overview The Follett Horizon ice machine uses a horizontal, cylindrical evaporator to freeze water on its inner surface.

  • Page 13: Water System

    Water system The water level in the evaporator is controlled by a feed solenoid and level detecting sensors. Referencing the diagram below, water sensing rods extend down into the reservoir at the end of the evaporator assembly. The system works via electrical conductivity as follows: One of the longest probes is a common.

  • Page 14: Electrical System

    Electrical system Normal control board operation The PC board indicator lights provide all the information necessary to determine the machine’s status. Green indicator lights generally represent “go” or normal operation; Yellow indicators represent normal off conditions; Red indicators generally represent alarm conditions, some of which will lock the machine off. A green light labeled POWER indicates power to the machine.

  • Page 15: Test Points

    Test points: The Horizon PC board incorporates on-board test points that can be used to determine various electrical outputs. The test point holes allow a standard probe to be inserted for quick voltage measurement. Error faults: The Horizon PC board monitors various operating parameters including high pressure, auger gearmotor amperage limits, clogged drain, and high and low water alarm conditions.

  • Page 16: Wiring Diagram, Evaporator Unit

    Wiring diagram, evaporator unit POWER (G) LOW BIN (G) AUGER ON (G) REFRIG ON (G) TIME DELAY (Y) CLEANING (Y) PURGE (Y) SERVICE (R) HI AMPS (R) HI PRESS (R) CONTROL PC BOARD LO PRESS (R) DRAIN CLOG (R) HI WATER (R) LO WATER (R) CPU (G) Gearmotor data (Brother)

  • Page 17: Wiring Diagram, Condenser Unit

    Single-phase condensing unit wiring diagram IMPORTANT: COMPRESSOR EQUIPPED WITH AN INTERNAL OVERLOAD FAN 1 PROTECTOR. ALLOW TIME FOR RESET. USE COPPER CONDUCTORS ONLY. FAN 2 COMPRESSOR CONTACTOR COIL POTENTIAL RELAY CRANK CASE HEATER COMPRESSOR CONTACTOR COMPRESSOR TERMINAL BLACK START CAPACITOR WITH BLEEDER RESISTOR CAPACITOR...

  • Page 18: Mechanical System

    Fig. 13 Mechanical system Evaporator disassembly 1. Press PURGE button to purge evaporator, and then turn power OFF. 2. Unscrew and remove stream divider as shown. Fig. 14 3. Unplug and remove gearmotor as shown. 4. Remove all traces of petrol-gel from the auger shaft. Fig.

  • Page 19: Evaporator Reassembly

    Fig. 16 8. Unscrew and disconnect transport tube from louvered docking assembly. 9. Unplug sensor at the electrical box. 10. Remove vent tube from shuttle housing as shown. Fig. 17 11. Remove and discard mating ring and seal. 12. Carefully remove auger. Fig.
  • Page 20 Fig. 19 3. Press new mating ring into main housing as shown. 4. Lube the shaft with liquid soap in the area shown and Cardboard slip on seal and spring. disc Note: Do not touch the sealing surfaces. Use cardboard disk to install.
  • Page 21 Fig. 22 11. Reconnect transport tube to louvered docking assembly. 12. Plug sensor in at the electrical box. 13. Reconnect vent tube to the shuttle housing as shown. Fig. 23 14. Apply a coat of petrol-gel to the auger shaft. 15.
  • Page 22 Fig. 25 17. Remove bolt and reinstall the washer and bolt. Place retainer over bolt and secure with nut and washer. Fig. 26 18. Lubricate body of stream divider with petrol-gel and reinstall. Apply 19. Plug gearmotor power cord into electrical box petrol-gel Horizon 1000R/N Ice Machines...

  • Page 23: Refrigeration System

    Refrigeration system Condenser unit operation The condensing unit is weatherproof and equipped to operate in ambient temperatures from -2 0 F to 120 F (-29 C to 48.9 C). The condensing unit is controlled by a low pressure control, which works in concert with a refrigerant solenoid valve on the evaporator module.

  • Page 24: Refrigeration System Diagram

    Refrigeration system diagram high side service valve with service port filter drier Condenser unit low side service valve with service port filter-drier compressor receiver 14 pounds sight glass high side service valve with service port low side service valve with service port condenser head control valve, 215 PSI check valve...

  • Page 25: Refrigerant Replacement Requirements

    Refrigerant replacement requirements 1. Non-contaminated refrigerant removed from any Follett refrigeration system can be recycled and returned to the same system after completing repairs. Recycled refrigerant must be stored in a clean, approved storage container. If additional refrigerant is required, virgin or reclaimed refrigerant that meets ARI standard 700-88 must be used.

  • Page 26: "Bin Full" Detection System

    “Bin full” detection system The Follett Horizon ice machine incorporates a unique “bin full” detection system, that consists of the shuttle and actuator. The shuttle incorporates a fl ag and sensor. Referencing the fi gure below, the normal running position of the fl ag is down, out of the sensor.

  • Page 27: Troubleshooting

    Troubleshooting Please see “Service” section for a description of each function. Ice machine disposition Possible causes Corrective action Legend: ON or OFF FLASHING Ice machine is in running 1. Defective compressor. 1. Replace compressor. condition but not making ice. 2. Defective start relay. 2.
  • Page 28 Ice machine disposition Possible causes Corrective action Legend: ON or OFF FLASHING 5. Ice machine is not making ice. 1. A self-fl ush occurred but could 1. Replace drain solenoid valve. Locked in PURGE. not drain evaporator due to a 2.
  • Page 29 This page intentionally left blank. Horizon 1000R/N Ice Machines...

  • Page 30: Replacement Parts

    Replacement parts Order parts online www.follettice.com Evaporator assembly 18 17 Horizon 1000R/N Ice Machines...
  • Page 31 Order parts online www.follettice.com Reference # Description Part # Tube, ice transport, molded 00175299 Shuttle assembly (includes gasket and nozzle) 00130815 Switch, optical 00130849 Compression nozzle 00115774 Elbow, water 00134502 Gasket, shuttle 00115600 Stream divider 00142513 Auger bolt 00116988 Washer 00161513 Retainer, auger bolt 00161356...
  • Page 32 Low side assembly Horizon 1000R/N Ice Machines...
  • Page 33 Reference # Description Part # Tubing, liquid line (includes insulation) 01012533 Tubing, suction line (includes insulation) 01012541 Sight glass 00107045 Electrical box support 00153635 Split system support bracket assembly 00151762 Valve, expansion, thermal (includes TXV insulation and bulb insulation) 00136317 Insulation, TXV 502830 Valve, shut-off, liquid line...
  • Page 34 Electrical box Order parts online www.follettice.com Reference # Description Part # Cover, electrical box, remote 00130898 Board, control circuit, 120 V (includes standoffs) 00132910 Stand off’s (set of 6) 00130906 Switch, evaporator purge 00114371 Switch, evaporator clean 00117036 Switch, ice machine power 208867 Circuit breaker, 8A 00128090...
  • Page 35 Integration kit – top-mount and RIDE model Order parts online Top mount configuration www.follettice.com RIDE model configuration Reference # Description Part # Shuttle actuator 00171322 Clamp 500377 Actuator elbow (includes gasket and screws) 00171264 Screws 209100 Gasket 00167122 Actuator body 00171272 Gasket, coupling 00126532...
  • Page 36 Skins assembly Order parts online www.follettice.com on Pl fic ati Ide nti ni a du le sy lva k Mo St oc le No st on Mo du G LE SI N uc t Pr od ice No Se rv C TE R AT R IA...
  • Page 37 Order parts online www.follettice.com Reference # Description Part # Front cover, split system 00130633 Tubing, water, 3/8" OD 502719 Tubing, drain 00144923 Fitting, drain 00109728 Fitting, water inlet 502924 Elbow, water inlet 502925 Coupling (includes O ring) 00171207 O ring 00144675 Bulkhead fi tting 00171215...
  • Page 38 Single-phase condensing unit Order parts online www.follettice.com Tecumseh Condensing Unit Date Code B1213 and before Reference # Description Part # Shroud 00155937 Condenser 00173062 Head pressure control valve 00110619 Condenser fan motor 00173070 Condenser fan guard 00123067 Receiver 00110627 Receiver service valve 00173047 Service valve, suction line 00173054...
  • Page 39 Single-phase condensing unit Order parts online www.follettice.com Tecumseh Condensing Unit After Date Code B1213 Top View Side View 20 12 Reference # Description Part # Shroud 01018290 Condenser 01018324 Head pressure control valve 01021401 Condenser fan motor 01018266 Condenser fan guard 00123067 Receiver 00991034...
  • Page 40 Harmony, Ice Manager, SafeCLEAN, Sani-Sponge and Vision are trademarks of Follett Corporation Chewblet, RIDE and Follett are registered trademarks of Follett Corporation, registered in the US. 801 Church Lane • Easton, PA 18040, USA 01034719R03 Toll free (877) 612-50861 • +1 (610) 252-7301 © Follet Corporation 11/13 www.follettice.com...
