HCD/HMD/HCF/HMF1010RHS, HCD/HMD/HCF/HMF1410RHS,
HCD/HMD1010NHS, HCD/HMD1410NHS
(See model number configurator on page 2 for details.)
After Serial Number L82638
and most countertop dispensers manufactured by
Horizon Elite
Ice Machine Models with RIDE
™
For applications using 110CM Symphony Plus
Cornelius • Lancer • Servend
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
Installation Instructions for Harmony
110CM Symphony
Technology
®
™
Plus Applications
™
remote condensing
01113232R02
or
Advertisement
Table of Contents
Related Manuals for Follett Horizon Elite HCD1010RHS
Summary of Contents for Follett Horizon Elite HCD1010RHS
- Page 1 Horizon Elite Ice Machine Models with RIDE Technology ™ ® Installation Instructions for Harmony ™ 110CM Symphony Plus Applications ™ HCD/HMD/HCF/HMF1010RHS, HCD/HMD/HCF/HMF1410RHS, HCD/HMD1010NHS, HCD/HMD1410NHS (See model number configurator on page 2 for details.) After Serial Number L82638 remote condensing For applications using 110CM Symphony Plus and most countertop dispensers manufactured by Cornelius •...
- Page 2 Chewblet Ice Machine Model Number Configurations ® 1810 Application Configuration Icemaker Voltage Series Condenser MC Maestro™ C 208-230/60/1 (icemaking head) 425 up to A Air-cooled, self-contained V Vision™ S RIDE™ Self-contained only. 425 lbs Chewblet ® W Water-cooled, self-contained H Harmony™ (RIDE remote D 115/60/1 (icemaking head) (193 kg)
- Page 3 Read and complete the following 8 installation steps Unpack Site preparation Dispenser preparation Docking assembly Ice transport tube External connection Internal connection Front cover HARMONY and Symphony Plus • RIDE Technology remote...
- Page 4 Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack carton #1 ➋ ➌ ➊ ➎ ➍ 7/16" DO NOT TILT ICE MACHINE TO ACCESS BOLTS! COMPRESSOR DAMAGE 7/16" WILL RESULT ➐ ➏ HARMONY and Symphony Plus • RIDE Technology...
-
Page 5: Site Preparation
• 10–70 psi (69–483 kpa) • 45–90 F (7–32 C) • Follett recommends the use of an in-line water filtration system (item# 00130286) • This equipment is to be installed with adequate backflow protection to comply with applicable federal, state, and local codes Drain ➌... -
Page 6: Dispenser Preparation
Dispenser preparation Prepare the dispenser. Attention! The location of the hole in the dispenser top is dependent on the type of dispenser. Be sure to follow Step 3.1 for the appropriate dispenser. Hole location - Harmony (Lancer, Cornelius or Servend), or 110CM Symphony Plus 30"... - Page 7 Top preparation Top preparation — – ˜ – • Remove protective tape from gaskets ➊ • Apply gaskets ➋ • Install shuttle actuator through dispenser top and secure with locking nut ➌ Top preparation — – • Screw 4" (102 mm) extension ➊...
- Page 8 Agitation adjustments – CORNELIUS E-BOARD AGITATOR TIMER MOTOR ON TIME: SET TO 1 SECOND TIME TIME MOTOR OFF TIME: SET TO 1 HOUR Cornelius models ED, DB, DF, IDC and FLAVOR FUSION Adjust the agitation timer located on the Cornelius PC board to 1 second on, 1 hour off. Note: See Cornelius manual or call Cornelius Technical Service at 1-800-238-3600 for more information.
- Page 9 Agitation adjustments – LANCER FS SERIES Initialization Screen (Boot Up Only) Lancer FS-16 Ver. 0.200 – Main Menu Sub-Catagory FS-16 Setup Brands Per Side Major/Minor V:1 L:2 R:1 FS-16 Setup Bonus Key Setup Config Bonus Key V:1 T:F M:S B:W FS-16 Setup Soda/Plain Water Cancel...
-
Page 10: Dispenser Diverter Plate Overview - Cornelius Ed, Df And Db Series (Installation On Next Page)
Dispenser diverter plate overview – CORNELIUS ED, DF and DB SERIES 3.10 (Installation on next page) Single Agitator P/N 307277 — Diverter plate (single agitator Cornelius dispensers and left-hand dispense chute on dual-agitator Cornelius dispensers) Dual Agitator P/N 307277 — Diverter plate (single agitator Cornelius dispensers and left-hand dispense chute on dual-agitator... - Page 11 3.11 Dispenser diverter plate installation – CORNELIUS ED, DF and DB SERIES GATE MOUNTING PLATE STORAGE HOPPER FLANGE EXTENDS INTO STORAGE HOPPER THROUGH GATE OPENING ICE DIVERTER ICE CHUTE COVER APPLY RTV TO THIS SURFACE TO SEAL TO HOPPER GATE MOUNTING PLATE 10-32 WASHER GASKET...
-
Page 12: Before Proceeding
Docking assembly Install the docking assembly. BEFORE PROCEEDING Prior to installing the docking assembly, ensure that the drain fitting is oriented (right or left) correctly for your installation. An optional straight drain fitting is also supplied. You may need to remove the back panel of the docking assembly in order to re-orient or change the drain fitting. - Page 13 Undercounter installation requirements Top View ➌ ➊ 3.25" (83 mm) min. Access panel/ door on counter 22.25" min. (656 mm) 24" min. (609 mm No Lip ➋ DOCKING STATION • Prior to installing the docking assembly, ensure that the drain fitting is oriented (right or left) correctly for your installation.
- Page 14 Transport tube Install the transport tube. Transport tube installation. Hot Water 160 F (71 C) 1/4" Ice transport tube tips • Insulate entire length of ice transport tube ➊ • Secure ice transport tube ➋ as needed to prevent dips and traps from forming. For long tube runs see guide on page 19.
-
Page 15: External Connections
External connections Connect utilities to docking assembly. Water and drain Refrigerant lines ➊ ➊ ➋ ➌ Minimum 8" ➏ radius 2 ft. x 1" OD silicone tubing • Braze supplied quick-connect lines onto stub-ins ➊ 3/4" barb x 3/4" FPT ➍... -
Page 16: Internal Connections
Internal connections Connect docking assembly to ice machine. Ice transport tube installation Water line ➋ ➊ ➋ ➊ • Slide ice machine into docking assembly • Insert potable water line into valve ➊ ensuring that drain tube is fully seated on ➊... - Page 17 TDS switch Power cord HIGH CLEAN • Set the TDS switch on the electrical box: • Position plate into opening and secure with supplied screw HIGH: for extended service life LOW: for low-scale water HARMONY and Symphony Plus • RIDE Technology remote...
-
Page 18: Front Cover
Front cover Install front cover to ice machine. Install condensing unit Install ice machine front cover ➋ ➊ ➊ • Slide ice machine cover over machine • Insert and tighten two screws through • Complete installation of condensing unit cover and into docking assembly ➋... - Page 19 Long tube run recommendations max. 2 ft (.6m) 1/4" • Pitch ice transport tube to allow melt water to drain towards ice machine ➊ • Secure insulated ice transport tube at least every 2 ft (0,6 m) to prevent dips or traps ➋...
- Page 20 Maestro, Micro Chewblet, Vision, Harmony, Ice Manager, Horizon, Horizon Elite are trademarks of Follett Products LLC. Chewblet, RIDE, Follett are registered trademarks of Follett Products LLC. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01113232R02 www.follettice.com...
