- Page 1 INSTALLATION AND OPERATION MANUAL AMD SERIES POWER AMPLIFIER AMD2100P...
-
Page 2: Important Safety Information
à la pluie ou à l’humidité. mains outlet with a protective earth connection. Un appareil avec la borne de terre de protection doit être connecté au secteur avec la connexiion de terre de protection. PAGE 2 AMD2100P INSTALLATION AND OPERATION MANUAL... -
Page 3: Introduction And Contents
INTRODUCTION AND CONTENTS AMD2100P INTRODUCTION FRONT PANEL The AMD P series of power amplifi ers from Australian Monitor represent a quantum leap forward in connectivity, controllability & REAR PANEL fl exibility in the constant voltage amplifi er market. The AMD series allows a contractor to integrate the power amplifi... -
Page 4: Front Panel
If this is happening the input should reduced using the input attenuator at the rear of the unit, or at the program source. Control Indicator The control indicator will fl ash whenever a control system adjusts a parameter inside the amplifi er. PAGE 4 AMD2100P INSTALLATION AND OPERATION MANUAL... -
Page 5: Rear Panel
230 to 240V or 115V to 120V Female XLR The power input is NOT auto-switching. Australian Monitor should be contacted if the voltage needs to be changed from its shipped confi guration. The power input also features a power switch, this is a hard power off and will shut down the unit completely. -
Page 6: Installation
Mounting when installing your AMD2100P amplifi er. The AMD2100P amplifi er is one rack units high (1U) and will fi t a standard EIA 19 rack. A rack rear support bracket is supplied and must be must be installed when rack mounting the amplifi er. The rear support bracket should be installed to the rack (rear rails) prior to mounting the amplifi... -
Page 7: Available Parameters
RS232 PROTOCOL Port & Protocol Information Channel Input Cross Mix Level: The RS232 port of the AMD2100P amplifi er’s consists of three connections: To adjust the volume control of an input cross mix level. Transmit – Data from the amplifi er *The Cross Mix commands allow any of the input channels to be mixed to a particular output channel. -
Page 8: Low Power Mode
(can range from 00 to FF) bb represents the minor fi rmware version number (can range from 00 to FF) cccc represents the fi rmware revision number (can range from 0000 to FFFF) PAGE 8 AMD2100P INSTALLATION AND OPERATION MANUAL... -
Page 9: Command Summary
FW version major num bb is the FW version minor num cccc is the FW version revision Get amp status %PAMP:x??<CR> %PAMP=xyy<CR> x ranges from 01 to 04 yy ranges from 00 to 02 PAGE 9 AMD2100P INSTALLATION AND OPERATION MANUAL... - Page 10 DIMENSIONS 482.00 mm (19.0”) 465.00 mm (18.3”) 430.00 mm (16.9”) 438.00 mm (17.25”) PAGE 10 AMD2100P INSTALLATION AND OPERATION MANUAL...
-
