  • Page 1 SERIES 120W / 250W POWER AMPLIFIERS INSTALLATION AND OPERATION MANUAL...

  • Page 2: Important Safety Information

    Do not parallel- or series-connect an amplifi er output with any other amplifi er output. Australian Monitor is not responsible 7. Always operate the unit with the AC ground wire connected to the for damage to loudspeakers for any reason.

  • Page 3: Table Of Contents

    INTRODUCTION AND CONTENTS The Australian Monitor Installation Series AMC+ range of booster amplifi ers INTRODUCTION take the rugged reliability of the famous AMIS range and deliver the same high quality audio reinforcement, in a low cost, 2 rack unit package. The AMC+ FRONT PANEL booster amplifi...

  • Page 4: Front Panel

    FRONT PANEL This LED indicates the unit is powered “on”. Power This switch switches power on or off the mains. The up position is on. Vents Air intake for fan cooling on AMC+250P only. PAGE 4 SERIES INSTALLATION AND OPERATION MANUAL...

  • Page 5: Rear Panel

    REAR PANEL Input Direct Out continued These 3 pin XLR sockets accept the source input for each Minimum Impedance 120P 250P channel. One input is a male XLR, the other is a female XLR. The male XLR is normally used as a thru output. When wiring from unbalanced sources, pins 1 and 3 should be Distributed Line Output shorted together (see Installation section).

  • Page 6: Installation

    INSTALLATION Mounting Direct Output When rack mounting, it is advisable to allow 1 rack space above and below the The output terminal strip accepts wire sizes from 16-22AWG amplifi er. When multiple amplifi ers are mounted in a rack, exhaust fans should (1.5mm2 –...

  • Page 7: Troubleshooting And Block Diagram

    Volume controls down Check volume controls Amplifi er has overheated Check for obstructions above and below Make sure the amplifi er is well ventilated DC fuse(s) blown Refer product to local Australian Monitor dealer SERIES INSTALLATION AND OPERATION MANUAL PAGE 7...

  • Page 8: Dimensions

    DIMENSIONS Dimensions the same for both the AMC + 120P and the AMC + 250P PAGE 8 SERIES INSTALLATION AND OPERATION MANUAL...

  • Page 9: Specifications

    SPECIFICATIONS 120P 250P POWER OUTPUT (0.5%THD, 1KHZ) 120W 250W S/N RATIO >88dB >88dB FREQ RESPONSE (-3dB +1dB) 50Hz-20kHz 40Hz-20kHz THD (1KHz, -1dB) Better than 0.5% Better than 0.5% INPUT SENSITIVITY 150mV 150mV (pot @ full) IMPEDANCE HEADROOM 10dB 10dB FUSES MAINS (115V) 6.3A MAINS (230V)

  • Page 10: Notes

    NOTES SERIES INSTALLATION AND OPERATION MANUAL PAGE 10...
  • Page 11 NOTES SERIES INSTALLATION AND OPERATION MANUAL PAGE 11...
