LevelOne OfficeCon GSW-0841 Specifications

8-Port
10/100/1000Mbps
w/ SFP Web Smart
H/W Version: 1
Gigabit Ethernet Solution
LevelOne GSW-0841 Gigabit switch equips 8
Gigabit ports that lead you to a real Gigabit
connection. Users are now able to transfer
large and high bandwidth-needed files faster
and hence get a real efficiency improvement.
In addiotion to the copper ports, the one of
the ports support fiber connection with the
equipped SFP ports for obtaining long-distance
communication.
Fast and Reliable Technology
GSW-0841 offers users with fast and reliable
network. The store-and-forward architecture
filters errors and forwards packets in a non-
blocking environment. Flow conrol ensures the
correctness of data transmitting. The 802.3x and
backpressure flow control mechanisms work
respectively for full and half duplex modes. This
device supports Nway auto-negotiation protocol
that detects the networking speed and the
duplex modes (Full/Half) automatically. Auto-
Key Features
- Complies with IEEE 802.3, 802.3u, 802.3ab and
802.3z
- 8 x 10/100/1000 Mbps RJ-45 Nway ports
- 1 x SFP for optional fibre optical
communication
- Up to 16Gbps Backplane bandwidth
- Supports 8K absolute MAC addresses entries
- Supports 180K Bytes RAM for data buffering
- Supports 9K bytes Jumbo frame
- Front-panel diagnostic LEDs
- Supports back-pressure (half duplex) and flow
control (IEEE 802.3x)

1 2
MDI/MDI-X function alleviates the effort to use
crossover cables
Web-based Management Interface
Friendly web management features are ready
for users easily to configure and maintain the
device through a general web browser. You
can partition the switch into 8 groups using
port-based VLAN technology. This switch also
supports Quality of Service (QoS) to prioritise
traffic for time-sensitive applicatio
Easy to Use
For instant error detection, the switch is
equipped with a full range of LEDs to help you
monitor and troubleshoot problems on your
network. The slim and unique design fits easily
in any space-limited location. Users can locate
the switch on the desktop. With the accessory
kits, the switch can ether be stacked or mounted
to the rack to save space.
3 4 5
Related Products
GSW-1657
16-Port Gigabit Ethernet Switch
GSW-2420
24-Port Gigabit Ethernet Switch
GSW-0841
1. LEDs
2. SFP Slot
3. 10/100/1000Mpbs Ports
4. Reset Button
5. Internal Power Socket
