Page 1: User Manual
LevelOne GSW-0504 GSW-0804 5/8-Port Gigabit Switch with internal power User Manual Version 2.0-0710... -
Page 3: Table Of Contents
Table of Contents Introduction ..............1 Features ...................... 1 Package Contents ..................2 Hardware Description..........3 Front Panel....................3 Rear Panel ....................3 LED Indicators..................... 4 Installation ..............6 Network Application ............ 7 Technical Specification ..........8 Appendix..............10 10 /100BASE-TX Pin outs ................. 10 10/100Base-TX Cable Schematic ............. -
Page 4: Introduction
Introduction GSW-0504/0804 5/8-Port Gigabit Switch is an ideal solution for solving traffic block at the core of the network. It offers 5/8 auto-negotiation 10/100/1000Base-T Gigabit Ethernet ports which can significantly improve your network backbone performance. Besides, this Switch will fit into any enterprise level network to act as an exit to the backbone switch. -
Page 5: Package Contents
Package Contents 5 / 8-port 10/100/1000 Mbps Gigabit Switch with internal power Power Cord Four Rubber Feet Stackable Kits User’s Manual 5/8-Port Gigabit Switch w/internal power Power Cord Stackable Kits Rubber Feet User Manual Figure 1-1. Package Contents Compare the contents of your 5 / 8-port 10/100/1000 Mbps Gigabit Switch package with the standard checklist above. -
Page 6: Hardware Description
Hardware Description This Section describes the hardware of the 5/8-Port Gigabit Switch. Front Panel The Front Panel of the 5/8-Port Gigabit Switch consists of LED-indicators (100/1000, Link/Activity, Full duplex/Collision) for each Gigabit port and power LED-indicator for unit. The details of LED indicator description refer to the LED Indicator section. -
Page 7: Led Indicators
LED Indicators The LED Indicators gives a real-time indication of system operating statuses. There are 3 LED-indicators (100/1000, LNK/ACT, FDX/COL) for The following table each Gigabit port and one Power LED for unit. provides descriptions of LEDs status and their meaning. Figure 2-3.LED Indicators Status Description... - Page 8 Blinking The port is receiving or transmitting data. No device attached. Orange The port is operating in Full-duplex mode. Blinking Packet collision occurred on this port. FDX/COL No device attached or in half-duplex mode. Table 2-1. The Descriptions of LED Indicators...
-
Page 9: Installation
Installation This section shows the installation procedures of the switch. Set the Switch on a sufficiently large flat space with a power outlet nearby. The surface where you put your Switch should be clean, smooth, level, and sturdy. Make sure there is enough clearance around the Switch to allow attachment of cables, power cord and air circulation. -
Page 10: Network Application
Network Application This section provides you one sample of network topology in which the 5/8-Port Gigabit Switch is used. In general, the 5/8-Port Gigabit Switch is designed as a high-bandwidth backbone switch. You can use the 5/8-Port Gigabit Switch to connect servers, switches, workstation, and PCs (Of course, the Gigabit 1000Base-T NIC has installed into the PC) to each other by connecting these devices directly to the Switch. -
Page 11: Technical Specification
Connector 5/8 Gigabit Copper: RJ-45; Auto-MDIX on all ports MAC Address 8K Mac address table Memory Buffer 112KB (GSW-0504); 114KB (GSW-0804) 10BASE-T: 2-pair UTP/STP Cat. 3, 4, 5 cable EIA/TIA-568 100-ohm (100m) 100BASE-TX: 2-pair UTP/STP CAT. 5 cable Network Cable EIA/TIA-568 100-ohm (100m) Gigabit Copper: 4 pair UTP/STP CAT. - Page 12 Per port: 100/1000, Link/Activity, Full duplex/ Collision Per unit: Power Power Supply 100~240VAC, 50~60Hz,internal power Power 5 port: 9.6Watt (maximum) Consumption 8 port: 12.8Watt (maximum) Operation 0℃ to 45℃ (32℉ to 113℉) Temperature Operation 10% to 90% (Non-condensing) Humidity Dimension 199mm x 147mm x 31.5 mm (W x D x H)
-
Page 13: Appendix
Appendix 10 /100BASE-TX Pin outs With10 /100BASE-TX cable, pins 1 and 2 are used for transmitting data, and pins 3 and 6 for receiving data. RJ-45 Pin Assignments Pin Number Assignment Note: “+” and “-” signs represent the polarity of the wires that make up each wire pair. -
Page 14: 10/100Base-Tx Cable Schematic
10/100Base-TX Cable Schematic The following two figures show the 10/100Base-TX cable schematic. Straight-through cable schematic Cross over cable schematic... -
Page 15: 10/100/1000Base-Tx Pin Outs
10/100/1000Base-TX Pin outs The following figure shows the 10/100/1000 Ethernet RJ-45 pin outs. 10/100/1000Base-TX Cable Schematic Straight through cables schematic... - Page 16 Cross over cables schematic...
