- Page 1 Raisecom Technology Co., Ltd RCMS2201/2401/2601-60 (REV.A) Modular Ethernet Multiplexer User Manual Raisecom Technology Co., Ltd...
- Page 2 Raisecom Technology Co., Ltd Cautions Please read the following notices carefully before installing and using the device, Raisecom does not respond to any loss that caused by violating safety notice. RCMS2201-30 is integrated device that has precise elements, please avoid violent shakes and impacts, and do not disassemble or maintain the device yourself.
-
Page 3: Table Of Contents
Raisecom Technology Co., Ltd Contents 1. Overview..........................1 1.1 Main Features ......................1 1.2 Part Number Explanation ..................2 2. Parameters ........................2 2.1 E1 Interface Specification ..................2 2.2 Fast Ethernet Interface Specification ..............3 2.3 Optical Interface Specification................3 2.4 Ambience ......................3 3. How to use........................3 3.1 Description of the Front Panel................3... -
Page 4: Overview
Ethernet data. RCMS2201-60 、 RCMS2401-60 和 RCMS2201/2401/2601-6 series is featured by high integration and complete network management functions. It can be installed into the Raisecom 3U-high 16-slot chassis, or desktop single-slot chassis, providing various network management functions. -
Page 5: Part Number Explanation
Single mode optical interface, 10-60 km 2 E1 channel 1 Ethernet interface Modular, dual-strand fiber-optic L2 Ethernet switching capability Multi-service Raisecom code (RC short for Raisecom) Note: Equipments that can work in pairs Host site Remote site Dual-strand RCMS2201-60-M RCMS2201-60-M... -
Page 6: Fast Ethernet Interface Specification
Raisecom Technology Co., Ltd 2.2 Fast Ethernet Interface Specification IEEE 802.3 IEEE 802.3u IEEE 802.1d Spanning Tree IEEE 802.1q VLAN Support oversized Ethernet data frame up to 1916 bytes Working mode: 10/100M Auto-Negotiation, Auto-MDI/MDIX (manual configurable) Flow control: IEEE802.3x and back pressure 2.3 Optical Interface Specification... -
Page 7: Dip-Switch
Optical Connector: SC type in the above figure, TX for transmitting direction, and RX for receiving direction The optical interface type of RCMS2201-60 is DSC/PC, The optical interface type of RCMS2401-60 and RCMS2601-60 is SC/PC. L/R ALM (Fiber Local or Remote Alarm) The red alarm indicator will be lightened when error occurs at local or remote optical receiving direction. -
Page 8: Fault-Pass-Through Capability Explanation
Raisecom Technology Co., Ltd Switch OFF (default status) Enable Ethernet interface auto-sensing Disable Ethernet interface auto-sensing Ethernet forced 100M when Ethernet forced when auto-sensing disabled auto-sensing disabled b)Invalid when auto-sensing enabled b) Invalid when auto-sensing enabled a) Ethernet forced full duplex when... -
Page 9: E1 Remote Loop-Back Test
When the equipment is connected as the following topology, the remote network management can be implemented. A． The host-site module is installed in Raisecom’s dedicated 16-slot 3U-high chassis, which also has the network management module installed. The remote-site module is installed in Raisecom’s single slot chassis. -
Page 10: Installation And Test
4.3 Installation This module can be installed into Raisecom’s dedicated 16-slot 3U-high chassis, 4-slot 1U-high chassis, and single slot chassis. Slowly insert the module into the slot to the end, and fasten the fixing screw tightly. -
Page 11: Function Configuration
Raisecom Technology Co., Ltd Pin 1, 2 for output of first E1 channel, pin 5, 6 for input of first E1 channel Pin 3, 4 for output of second E1 channel, pin 7, 8 for input of second E1 channel Ethernet Interface Connect with Cat. -
Page 12: Appendix A Cable Making
120ohm balanced E1 interface of other equipment as per above table. When user needs 75ohm unbalanced E1 interface, twisted-pair can be connected to E1 impedance converter. RC909-1E1 is single E1 channel impedance converter of Raisecom. Following is connecting figure of RCMS2201-60/ RCMS2401-60/ RCMS2601-60 and RC909-1E1... -
Page 13: Ethernet Cable Making
Raisecom Technology Co., Ltd A.2 Ethernet Cable Making Use Cat.5 twisted-pair cable with RJ45 connector to connect this equipment. Note that the cable shall not be longer than 100 meters. The cable can be either straight-through or crossover. The sequence of the RJ45 connector is as follows. - Page 14 Raisecom Technology Co., Ltd @2005 Raisecom Technology Co., Ltd. All trademarks are the property of their respective owners. Technical information may be subject to change without prior notification. - 11 -...
