Mercury Switch User Guide
Setup Function Menu

Recommended set-up method

Set/View Type

a. From the function menu scroll to select type and press enter
b. The current type is shown. Use the up/down buttons to scroll through the configuration types.
c. Select the desired number and press enter.
There are 4 types: -
Type Description
1 Degree C/ Bar
2 Degree C/ PSI
3 Degree F/ Bar
4 Degree F/ PSI

Set/View Parameters (This can also be achieved at the network front end)

a. From the function menu scroll to select PArA
b. Pressing Enter while PArA is displayed will enter the parameter menu. The first parameter option will be displayed as P-
01. Pressing the Up or Down button will present the other parameter options P-02, P-03 etc. See the parameter table to
find what parameter number corresponds to which actual parameter. Pressing the Enter button will show the current
value of the selected parameter. Press Up or Down to modify the value and press Enter again to save the value. The
parameter list number will be displayed again. Two other options are present in the parameter menu – dFLt and ESC.
Selecting ESC will exit setup mode. Selecting dFLt will reset all parameters back to the default values for the current type
of controller.
ID
Allows the user to assign a unique three digit software address to the Mercury Switch. Note this is only required when the Mercury Switch
is in IP-L mode.
a. From the function menu scroll to select Id
b. The current id number will be shown. Use the up/down buttons to scroll through from 000 to 999.
c. Select the desired number and press enter to save.

Network Configuration

Unlike the PR0018 (Standard Mercury Switch version) when this product is used with a Data Manager/Data Director it is registered on
the system as a device. Once the Mercury Switch is on-line, the Switch type and parameters can be set up. The switch comes online with
the ID of the 2 rotary switch settings followed by the letter a. For example with the first rotary switch set to 4 and the second switch set to
8 then the switch would appear as device "48a". If a DHCP server is present on the IP network set the 2 rotary network switches to an
appropriate setting, the Mercury Switch has an auto-initialise function, which will automatically log the device onto the site network. If the
wrong ID has been entered onto the network, you will have to reset the Switch ID by setting the ID to 0-0, power cycle and then re-enter
the correct ID.
This Switch does not require an external communications module.
Warning
Ensure that all power is
switched off before
installing or maintaining
this product
Display Option
IO View Input and Output States
PArA View or change Parameters
ID View or change ID
tyPE View or change Controller Type
nEt View or change the Network Settings
SoFt View the Software version
ESC Escape the menu
Explained in Paragraph
IO
PArA
ID
type
Network Configuration
Revision 2.1D Page 6 of 14
