Mercury Switch User Guide

Network Alarms

The table below shows the text and associated type number that is sent to the system "front end". The type number is normally used to
provide different alarm actions.

Setup via Webpages

The Mercury Switch can be configured by navigating to the Mercury Switch WebPages. This can be achieved by using the Controller Info
page in the Data Manager/Data Director. Find the IP address assigned to the Mercury Switch in question from the list. Now connect a
laptop onto the IP network on which the Mercury Switch is connected. Using a web browser navigate to the IP address of the Mercury
Switch. The homepage of the Mercury Switch is shown below: -
Click on "Configure" to set the type: -
Then click "Type"
Use the drop-down selection to select the type required and then click "Set Type". Parameters can be changed using the connection as
illustrated above or through the normal Data Manager/Director change parameter routes or through the display if fitted (PR0445).
Warning
Ensure that all power is
switched off before
installing or maintaining
this product
Alarm text
Transducer Fault
High Pressure Alarm
MOP Alarm
Remote Pressure
Revision 2.1D
Type # (Index)
6
8
3
6
www.resourcedm.com
Page 13 of 14
