Mercury Switch User Guide

IP-L (Local IP Address)

To configure the Mercury Switch for IP-L, set both rotary switches to zero.
1. nEt. From the function menu you can now select nEt

IP-r (IP Address issued by the DHCP server)

To configure the Mercury Switch for IP-r, set the two rotary switches to give each controller a unique identifier. The controller should then
be connected to the network.
2. nEt. From the function menu you can now select nEt
To ease setup, a single network mask length value is used. If the address has been specified with a network mask value in dotted IP
format e.g. 255.255.255.0 then the table below gives the conversion:
Warning
Ensure that all power is
switched off before
installing or maintaining
this product
Press enter and the display will show "IP-L", press enter
You can now set the address using the table below
Display Option
IP-1 IP Address byte 1
IP-2 IP Address byte 2
IP-3 IP Address byte 3
IP-4 IP Address byte 4
nL Network Mask Length
gt-1 Gateway Address byte 1
gt-2 Gateway Address byte 2
gt-3 Gateway Address byte 3
gt-4 Gateway Address byte 4
ESC Exit network menu. N.B. this option must be selected to save
any changes made in this menu
Press enter and the display will show "IP-r", press enter
You can now view only the address given by the DHCP server
Mask Length
255.255.255.252
30
255.255.255.248
29
255.255.255.240
28
255.255.255.224
27
255.255.255.192
26
255.255.255.128
25
255.255.255.0
24
Mask Length
255.255.254.0
23
255.255.252.0
22
255.255.248.0
21
255.255.240.0
20
255.255.224.0
19
255.255.192.0
18
255.255.128.0
17
255.255.0.0
16
Revision 2.1D
Mask Length
255.254.0.0
15
255.252.0.0
14
255.248.0.0
13
255.240.0.0
12
255.224.0.0
11
255.192.0.0
10
255.128.0.0
09
255.0.0.0
08
www.resourcedm.com
Page 7 of 14
