Mercury Switch User Guide
Specification
Power requirements
Supply Voltage Range
Supply Frequency
Typical Supply Current
Maximum Supply Current
General
Operating Temperature Range
Operating Humidity
Storage Temperature Range
Environmental
Size
Weight
Safety
EMC
Disposal
Origins
Ventilation
Class 2 Insulation
The host equipment must provide a suitable external over-current protection device such as: -
Fuse
Or MCB
Mounting
There is a fixing lug at each end of the Switch, with hole centres 317 mm apart. Use typically Number 6 x 1" Pan head screw with 6mm
washer, torque down to 1.5 Newton metres.
RS232 Cable Lengths
All RS232 connections must not exceed 15 metres/connection.
Ethernet Cable lengths
Port number
1
2
3
Disclaimer
The specifications of the product detailed in this document may change without notice. RDM Ltd shall not be liable for errors or
omissions, for incidental or consequential damages, directly or indirectly, in connection with the furnishing, performance or misuse of this
product or document.
Revision
2.1D
Warning
Ensure that all power is
switched off before
installing or maintaining
this product
100 – 240 Vac ±10%
50 – 60 Hz
<500mAmps
650mA
0
0
+5
C to +50
C
80% maximum
0
0
-20
C to +65
C
Indoor use at altitudes up to 2000m, Pollution Degree II,
Installation Category II.
300mm (L) x 35mm (H) x 110mm (W)
300 Grams
EN61010
EN 55022
EN 55024
EN 61000-3-2
EN 61000-3-3
Attention this is a Class A product. When used in a domestic environment this device may cause
radio interference, in which case the user may be required to take adequate measures.
Please observe local legislation with regards to electrical products.
Product designed in the UK manufactured in Taiwan.
There is no requirement for forced cooling ventilation
No protective Earth is required and none should be fitted.
1A 240 Vac Antisurge (T) HRC conforming to IEC 60127
1A, 240 VAC Type C conforming to BS EN 60898
Main Powered Switch
Refer to Cat5 standard
Refer to Cat5 standard
Refer to Cat5 standard
Revision History
Date
Changes
21/02/2012
Current Release
Revision 2.1D
Page 14 of 14
www.resourcedm.com
