PR0710
PR0711
4 Port USB Hub User Guide
Resource Data Management Ltd
80 Johnstone Avenue, Hillington Industrial Estate,
Glasgow, Scotland, G52 4NZ, UK
+44(0)141 810 2828
support@resourcedm.com
sales@resourcedm.com
www.resourcedm.com
Switchboard
Technical Support
Sales Enquiries
PR0624
Advertisement
Related Manuals for Resource Data Management PR0624
Summary of Contents for Resource Data Management PR0624
- Page 1 PR0710 PR0711 PR0624 4 Port USB Hub User Guide Resource Data Management Ltd 80 Johnstone Avenue, Hillington Industrial Estate, Glasgow, Scotland, G52 4NZ, UK +44(0)141 810 2828 Switchboard support@resourcedm.com Technical Support sales@resourcedm.com Sales Enquiries www.resourcedm.com...
- Page 2 4 Port USB Hub User Guide Connections The 4 Port USB Hub is used to expand the available USB ports on a host device to allow for additional USB connections. The 4 port USB hub connects to a number of RDM products such as the Plant Controller or the Data Manager. The Hub requires a 24V ac or dc supply to operate. The “USB Device”...
- Page 3 4 Port USB Hub User Guide USB Cable A USB cable comes supplied with the Hub and the cable is 40cm in length. The USB cable has an A type USB connection at one end, which connects to the host device and a B type USB connection which connects to the USB 4 port “USB Device”...
