ML Switch User Guide

Power requirements:

Supply Voltage Range:
Supply Frequency:
Typical supply current:
Maximum supply current
Operating temperature range:
Operating Humidity:
Storage temperature range:
Environmental:
Size:
Weight:
Safety:
EMC:
Ventilation:
Class 2 Insulation:
The host equipment must provide a suitable external over-current protection device such as: -
Fuse:
Or MCB:

Mounting

There is a fixing lug at each end of the Switch, with hole centres 317 mm apart. Use typically Number 6 x 1" Pan head screw with 6mm
washer, torque down to 1.5 Newton metres.

RS232 Cable Lengths

All RS232 connections must not exceed 15 metres/connection.

Ethernet Cable lengths

Port number
1
2
3

Disclaimer

The specifications of the product detailed in this document may change without notice. RDM Ltd shall not be liable for errors or
omissions, for incidental or consequential damages, directly or indirectly, in connection with the furnishing, performance or misuse of this
product or document.
Revision Date
1.2 04/05/2009
1.2A 20/07/2009
1.2C 24/02/2012
1.2D 26/07/2012
Warning
Ensure that all power is
switched off before
installing or maintaining
this product
100 - 240 Vac ±10% (Mains version)
50 - 60 Hz (Mains version)
<500 mAmps
650mA
0 0
+5 C to +50 C
80% maximum
0 0
-20 C to +65 C
Indoor use at altitudes up to 2000m, Pollution Degree 1,
Installation Category II.
Voltage fluctuations not to exceed ±10% of nominal voltage
300mm (L) x 35mm (H) x 110mm (W)
300 Grams
EN61010
EN61326; 1997 +Amdt. A1; 1998
There is no requirement for forced cooling ventilation
No protective Earth is required and none should be fitted.
1A 240 Vac Antisurge (T) HRC conforming to IEC 60127
1A, 240 VAC Type C conforming to BS EN 60898
Main Powered Switch
Refer to Cat5 standard
Refer to Cat5 standard
Refer to Cat5 standard
Changes
st
1 released copy. Revision history synchronised with ML Switch software
version.
Note on network compatibility with new Switch and IP Module added
Current Issue
New Look

Specification

Revision History

Revision 1.2D
Comments
