Your VP-4x8AK 4x8 VGA / UXGA / Audio Matrix Switcher

Table 2: Front Panel VP-4x8AK 4x8 VGA / UXGA / Audio Matrix Switcher Features

# Feature
1 IR Receiver
2 POWER LED
3 SELECTOR OUT
Buttons
4 SELECTOR IN
Buttons
5 ALL Button
6 OFF Button
7 VIDEO Button
8 AUDIO Button
9 AFV Button
10 STO (Store) Button
11 RCL (Recall) Button
12 TAKE Button
13 - Button
AUDIO
LEVEL
14 + Button
15 LOCK Button
16 STATUS 7-segment
display
17 REL. AUDIO LEVEL
7-segment display
1 From 1 to 8
2 For example, press ALL and then Input button # 2 to connect input # 2 to all the outputs
3 The VIDEO button is illuminated when in breakaway mode and actions relate to video
4 The AUDIO button is illuminated when in breakaway mode and actions relate to audio
5 For example, press STO and then the output button # 3 to store in Setup # 3, or the input button 4 to store in Setup 12
6 When in the Confirm mode, the TAKE button illuminates
7 Also displays the number of INPUT and OUTPUT ports, the firmware version number, and the MACHINE #. Refer to
8 A dot following the number, represents a value of 0.5. For example, 3.5 displays as "3."
9 The input audio level ranges from -100dB to +20dB and the output audio level ranges from -100dB to +7.5dB
Function
The yellow LED is illuminated when receiving signals from the infrared
remote control transmitter
The green LED is illuminated when the unit is turned ON
1
Select the output to which the input is switched
Select the input (from 1 to 4) to switch to the output (after selecting an
output).
When a signal is detected at an input connector, the corresponding input
button is illuminated
Pressing ALL followed by an INPUT button, connects that input to all outputs
Press an OUT SELECTOR button and then an OFF button to disconnect that
output from the inputs.
Press the ALL button and then the OFF button to disconnect all the outputs
3
When pressed actions relate to video. Press the VIDEO button together with
the AUDIO button to set the Switching delay time (see
4
When pressed actions relate to audio. Press the VIDEO button together with
the AUDIO button to set the Switching delay time (see
When pressed, the audio channels follow the video channels. The button is
illuminated when the AFV mode is selected
Pressing STO followed by an input/output button stores the current setting
Press the RCL button together with the STO button to set the machine
number (see Section 6.8
Pressing the RCL button and the corresponding IN/OUT button recalls a setup
from the non-volatile memory.
Press the RCL button again to implement the new status
Press the RCL button together with the STO button to set the machine
number (see Section 6.8)
Pressing TAKE toggles the mode between the Confirm mode
At Once mode (user confirmation per action is unnecessary). When in
Confirm mode, pressing the TAKE button will implement a pending
configuration
Press to decrease the input or output audio signal level
Press to increase the input or output audio signal level
Disengages the front panel switches
Displays the selected INPUT switched to the OUTPUT (marked above each
7
input)
8
Displays the relative audio level
)
9
2
Section 6.7 )
Section 6.7 )
5
6
and the
Section 7.2.1
7
